Phoenix Contact 2801292 PT-IQ-5-HF+F-5DC-PT surge protection

In stock
SKU: 566978
€204.03
Into a basketIn the basketGo

Overview

Surge protection, consisting of protective plug and base element, with integrated multi-stage status display on the module for five signal wires. For HF applications and telecommunications interfaces without supply voltage (up to 90 Mbit/s).

Property Value
Signaling on the device: optical
Mounting type: other
Nominal discharge current (8/20): 10 kA
Nominal load current: 0.6 A
Connection 1: Terminal
Maximum continuous voltage DC: 6 V
Highest continuous voltage AC: 4 V
Protection level wire/wire: 30 V
Protection level wire/earth: 900 V
Protection level wire/signal ground: 90 V
With remote signaling contact: no
Explosion-tested version: no
Nominal voltage DC: 5 V

Characteristics

Explosion-tested versionNo
With remote signaling contactNo
Connection 1Clamp
Highest continuous voltage DC6 V
Nominal load current0.6 A
Nominal voltage DC5 V
Protection level wire/wire30 V
Protection level wire/earth900 V
HABPT-IQ-5-HF+F-5DC-PT
ManufacturerPhoenix Contact
HAN2801292
GTIN4046356766739
Highest continuous voltage AC4V
Mounting typeOther
Nominal discharge current (8/20)10kA
Signaling on the deviceOptical
