Pollmann 2217402 G-4L-210ML12TE fork phase rail

Pollmann 2217402 G-4L-210ML12TE fork phase rail

In stock

SKU: 551105

Price on request

€11.03

€0

Into a basketIn the basketGo

Overview

Mini-Line system, 10 mm2, must not be sawed!, connection screw: M 6, insulation material: PA 6.6 GV 25, 4-phase for LS or 4-pole FI and LS+N:

Property	Value
Number of phases:	4
Length:	210 mm
Cross-section:	10 mm²
Rated continuous current Iu:	100 A
Max. Rated operating voltage Ue:	500 V
Insulated:	yes
Suitable for number of devices:	12
Suitable for devices with N-conductor:	no
Pitch:	17.8 mm
Suitable for devices with auxiliary switch:	no
Conditional rated short-circuit current Iq:	50 kA
Design of the electrical Connection:	Fork
Rated impulse voltage:	4 kV

Characteristics

Suitable for devices with auxiliary switchNo

Suitable for devices with N conductorNo

Suitable for number of devices12

Pitch dimension17.8 mm

Rated surge voltage4 kV

HAB2217402 G-4L-210ML12TE

Manufacturer

HAN2217402

GTIN4025221021104

Number of phases4

Design of the electrical connectionFork

Conditional rated short-circuit current Iq50kA

Rated continuous current Iu100A

IsolatedYes

Length210 mm

Max. rated operating voltage Ue500V

Cross-section10 mm²
