Equipotential bonding rail according to DIN EN 62561-1 with plastic insulators for protective and functional equipotential bonding according to DIN0100 Part 410/540 and lightning protection equipotential bonding according to DIN EN 62305-3. Material: copper. Dimensions (length x width x thickness): 640 x 40 x 5 mm. Number of connections: 18. Connection holes: 11 mm. Material of screws: stainless steel V2A. Connection screws: [18x], carriage bolt M10 with nut and spring washer. Rail fastening: [3x], hexagon screw M8 with spring washer. Wall fastening: [3x] shoulder screw M8 St/gal Zn with plastic dowel 10x50. Insulators: [3x] threaded connection M8, SW 32, height 35 mm. Short-circuit current (50 Hz), 1 s, 300 °C:. 39 kA
