ColorAnthracite
Bridging switchNo
With signal unitNo
Number of switching zones1
Response brightness5 to 1000 lx
Forced shutdownNo
Max. inrush current16 A
Scanning angle220 °
Forced switching onNo
HANEE861
GTIN3250612258642
Connection typeOther
Response sensitivity adjustableYes
Response brightness adjustableYes
Antibacterial treatmentNo
Surface finishFrosted
Width91 mm
Detection angle horizontal220°
Remote controllableYes
Frequency50 to 60 Hz
Suitable for C-loadYes
Suitable for ceiling mountingYes
Suitable for wall mountingYes
Suitable for wireless transmissionNo
HVAC controlNo
Halogen freeYes
Height139 mm
Constant light controlNo
Max. duty cycle30 min
Max. range frontal16m
Max. range to one side10m
Max. switching capacity2300W
Min. duty cycle5s
With DALI interfaceNo
With remoteYes
Mounting typeSurface-mounted
Extension inputYes
SurfaceUntreated
Optimal mounting height4m
Impact resistanceIK03
IP protection)IP55
Voltage typeAC
Teach function for response brightnessYes
Depth153 mm
Animal corridorNo
Staircase monitoringNo
Creep protection/rear field monitoringNo
NetworkableYes
MaterialPlastic
Material qualityThermoplastic
