BEG 92931 PD9-M-1C-SDB-IP65-GH-DE white Luxomat presence detector

BEG 92931 PD9-M-1C-SDB-IP65-GH-DE white Luxomat presence detector

In stock

SKU: 389471

Price on request

€163.38

€0

Overview

Mini presence detector especially for damp rooms with high ceilings, One potential-free switching contact, Designed as a master device, An additional slave device can be connected directly, Additional functions can be set via optional remote control, Spring terminals for quick and easy installation in suspended ceilings and in lights, Including 45 mm cover ring and cover slat

Property	Value
Height:	40.0 mm
Version:	Presence detector
Color:	white
Nominal voltage:	230 V
RAL number (similar):	9010.0
Material:	Plastic
Mounting type:	other
Response brightness:	20 to 2000 lx
Protection class (IP):	IP65
Max. Switching capacity:	2300 W
Voltage type:	AC
Max. range to one side:	1.75 m
Suitable for wall mounting:	no
Min. duty cycle:	15 s
Max. Duty cycle:	30 min
Creep-under protection/rear field monitoring:	yes
Temperature:	-25 to 50 °C
Adjustable response brightness:	yes
Adjustable response sensitivity:	yes
Max. Inrush current:	80 A
Sensor type:	passive infrared
Optimal installation height:	6 m
Surface finish:	matt
Surface:	untreated
Material quality:	other
Detection field diameter on floor:	6 m
Control current:	10 mA
Number of switching zones:	9.0
Frequency:	50 Hz
Halogen-free:	yes
HVAC control:	no
Forced shutdown:	yes
Animal corridor:	no
Networkable:	no
Staircase monitoring:	yes
Bypass switch:	no
Suitable for wireless transmission:	no
Remote controllable:	yes
With signal unit:	no
Alarm function:	no
Teach function for Response brightness:	no
Dimming function with dimming insert:	no
Transparent:	no
With remote control:	no
Suitable for C load:	no
With DALI interface:	no
Extension input:	yes
Suitable for ceiling mounting:	yes
Antibacterial treatment:	no
Impact resistance:	IK03
Diameter:	36.0 mm

Characteristics

Bridging switchNo

With signal unitNo

Number of switching zones9.0

Response brightness20 to 2000 lx

Forced shutdownYes

Max. inrush current80 A

HABPD9-M-1C-SDB-IP65-GH-DE white Luxomat

Manufacturer

HAN92931

GTIN4007529929313

Dimming function with dimming insertNo

Alarm functionNo

Response sensitivity adjustableYes

Response brightness adjustableYes

Antibacterial treatmentNo

Version

Surface finishFrosted

Diameter36.0 mm

Detection field diameter on floor6m

Color

Remote controllableYes

Frequency50Hz

Suitable for C-loadNo

Suitable for ceiling mountingYes

Suitable for wall mountingNo

Suitable for wireless transmissionNo

HVAC controlNo

Halogen freeYes

Height40.0 mm

Max. duty cycle30 min

Max. range to one side1.75m

Max. switching capacity2300W

Min. duty cycle15s

With DALI interfaceNo

With remoteNo

Mounting typeOther

Extension inputYes

Nominal voltage

SurfaceUntreated

Optimal mounting height6m

RAL number (similar)9010.0

Impact resistanceIK03

IP protection)IP65

Sensor type

Voltage typeAC

Teach function for response brightnessNo

Temperature-25 to 50 °C

Animal corridorNo

TransparentNo

Staircase monitoringYes

Creep protection/rear field monitoringYes

NetworkableNo

MaterialPlastic

Material qualityOther
