8 inputs for direct or alternating voltage in the range of AC/DC 12...230 V , - 8 relay contact outputs electrically interlocked in pairs for controlling 4 sun protection drives for AC 230 V , - Contact rated operating voltage AC 230 V , - Contact rated operating current 6 A, cos phi = 1 , - Power supply of the electronics via integrated power supply unit for AC 230 V , - Device also works without a bus connection or if the bus communication fails , - Default setting in the delivery state for direct control of the outputs via blind button function via buttons connected to the inputs , - Button for switching between bus and direct operation , - One button per relay contact output to switch the output on in direct operation for the duration of the button operation , - With bus connection with optional joint or individual parameterization of the inputs , - Per Input adjustable function: , - Switching state, send binary value , - Switching edge, short/long , - 1-button dimming, sun protection control, group control , - 1-bit/8-bit scene control , - 8-bit/16-bit value edge, short/long , - 16-bit floating point value edge, short/long , - Function adjustable per input pair: , - Directly acting on the associated outputs as blind button , - 2-button dimming with stop telegram or with cyclical sending , - 2-button sun protection control , - Selectable blocking of each input via an associated blocking object , - Sending of the input objects after change , - Selectable cyclical sending of the input objects , - Communication objects per blind channel for moving the sun protection to the end positions or for stopping the process and for step-by-step adjustment of blind slats, - communication objects for directly moving to a position of the sun protection and the blind slats using position information as a percentage, - automatic opening of the blind slats up to a parameterized target position after the blind has been lowered continuously from the upper to the lower end position, with integrated 1-bit scene control for saving and calling up (restoring) 2 intermediate positions of the blind and slats, - integrated 8-bit scene control and integration of each channel in up to 8 scenes, - optional sun object for activating/deactivating the sun tracking control of the blind slats when shading with the greatest possible proportion of daylight, - differentiation between automatic and manual operation as well as with automatic switching from automatic to manual operation of the affected channel when a bus button is pressed for manual control of the associated sun protection, - integrated bus coupler, bus connection via bus terminal or contact system to the data rail , - Modular device for mounting on TH35 rail DIN EN 60715
| Property | Value |
| Mounting type: | REG |
| Max. number of blind outputs: | 4 |
| Number of inputs: | 8 |
| Type of current: | AC |
| Max. Switching capacity: | 1380 W |
| Width in modular spacing: | 8 |
| Switching current ohmic: | 6 A |
| Protection class (IP): | IP20 |
| KNX bus system: | yes |
| Radio bus system: | no |
| Powernet bus system: | no |
| With bus connection: | yes |
| Bus system LON: | no |
| Other bus systems: | without |
| Local/manual operation: | yes |
| With LED display: | yes |
| Switching function: | no |
| KNX radio bus system: | no |
| Bidirectional radio: | no |
| Removable bus module: | no |
