Siemens 6XV1871-2L Industrial Ethernet FOOD cable 2x2 PROFINET type C

In stock
SKU: 365478
€4.06
Into a basketIn the basketGo

Overview

Industrial Ethernet FC TP FOOD Cable GP 2x2 (PROFINET Type C) TP installation cable for use in the food and beverage industry, 4-core CAT5E, sold by the meter, delivery unit max. 1000m, minimum order quantity: 20m. SIMATIC NETIE FC TP Food Cable 2x2 (Type C)Flexible bus cable for use in the food and beverage industry.Time saving through simple and quick on-site assembly. Interference-resistant network thanks to double-shielded cables and consistent grounding concept. Exceeds category 5 (Cat5e) of the international cabling standards ISO/IEC 11801 and EN 50173. Easy length determination thanks to printed meter marking.

Property Value
Number of cores: 4
Outer diameter approx.: 6.5 mm
Category: 5E
Low smoke according to EN 61034-2: no
Sheath color: black
Conductor diameter: 0.75 mm
Number of stranding elements: 2
Sheath material: other
Permissible external cable temperature during assembly/handling: -50 to 60 °C
Permissible External cable temperature after installation without vibration: -40 to 75 °C
NVP value: 66 %
Specification of sheath material: Polyethylene (PE)
Fire behavior class according to EN 13501-6: Fca
Min. permissible bending radius, flexible use with forced guidance: 49 mm
Min. permissible bending radius, flexible use/free movement: 49 mm
Min. permissible bending radius, stationary use/permanently installed: 49 mm
Laying in the ground: no

Characteristics

Sheath materialOther
Outer diameter approx.6.5 mm
Category5E
Conductor diameter0.75 mm
HAB6XV1871-2L 2x2 PROFINET Type C
Minimal order20 meters
ManufacturerSIEMENS
HAN6XV1871-2L
GTIN4019169852838
Wire number4
Coat colorBlack
Siemens 6XV1871-2L Industrial Ethernet FOOD cable 2x2 PROFINET type C
