Siemens 6XV1871-2S Industrial Ethernet FESTOON cable 2x2 PROFINET type B

In stock
SKU: 340871
€5.88
Into a basketIn the basketGo

Overview

Industrial Ethernet FC TP FESTOON Cable 2x2 (PROFINET Type B), TP installation cable for festoon suspension, 4-core CAT5E, sold by the meter, min. 5 million bending cycles, delivery unit max. 1000m, minimum order quantity 20m. SIMATIC NETIE FC TP Festoon Cable GP 2x2 (Type B)Flexible bus cable for use with constant movement in a cable trail, festoon use.Time saving through simple and quick on-site assembly. Interference-resistant network thanks to double-shielded cables and consistent grounding concept. Silicone-free, making it suitable for use in the automotive industry (e.g. paint shops). Exceeds category 5 (Cat5e) of the international cabling standard ISO/IEC 11801 and EN 50173. Easy length determination thanks to printed meter marking.

Property Value
Number of cores: 4
Outer diameter approx.: 6.5 mm
Category: 5E
Low smoke according to EN 61034-2: no
Conductor diameter: 0.75 mm
Number of Stranding elements: 2
Sheath material: Polyvinyl chloride (PVC)
Perm. Cable external temperature during assembly/handling: -50 to 60 °C
Perm. External cable temperature after installation without vibration: -40 to 75 °C
NVP value: 66 %
Specification of sheath material: other
Fire behavior class according to EN 13501-6: Eca
Min. permissible bending radius, flexible use with forced guidance: 70 mm
Min. permissible bending radius, flexible use/free movement: 70 mm
Min. permissible bending radius, stationary use/permanently installed: 70 mm
Laying in the ground: no

Characteristics

Sheath materialPolyvinyl chloride (PVC)
Outer diameter approx.6.5 mm
Category5E
Conductor diameter0.75 mm
HAB6XV1871-2S 2x2 PROFINET Type B
Minimal order20 meters
ManufacturerSIEMENS
HAN6XV1871-2S
GTIN4019169852821
Wire number4
