Kleinhuis 514GFKM40 metric M40 screw plug

In stock
SKU: 796146
€0.79
Into a basketIn the basketGo

Overview

Closing screw with metric connection thread according to DIN EN 60423, glass fibre reinforced, with flame retardant, halogen-free. Nominal size: M 40 Connection thread length: 8 mm Operating temperature range: -40° to 100°C Glow wire test according to DIN EN 60695-2-10+11/VDE 0471-2-10+11: 650°C Protection class: IP54 with connection thread sealing ring 987M... (please order separately!): IP68 Material: Polyamide Color: light gray RAL: 7035 (similar)

Property Value
Thread pitch: 1.5 mm
Nominal thread size metric/PG: 40
Thread type: metric
Fiberglass reinforced: yes
Impact resistant: yes
Material: Plastic
Material quality: Polyamide (PA)
Surface: untreated
Halogen free: yes
Color: light gray
Explosion-tested Version: no
For Ex-Zone Gas: without
For Ex-Zone Dust: without
RAL number: 7035

Characteristics

Impact resistantYes
Explosion-tested versionNo
Nominal thread size metric/PG40
Fiberglass reinforcedYes
HABMetric M40
ManufacturerKleinhuis
HAN514GFKM40
GTIN4011126366655
Thread typeMetric
Thread1.5 mm
Halogen freeYes
SurfaceUntreated
RAL number7035
MaterialPlastic
Material qualityPolyamide (PA)
