For roller shutters, screens, Venetian blinds and windows. For individual control of a 230 V drive via ring line IB+ or locally via button. Local setting of an intermediate position and the operating ergonomics. - Easy operation thanks to ergonomic design: Sensitive technology - Quick commissioning in combination with TouchBuco, animeo Building Controller or control devices such as Chronis Smoove IB+ and Soliris Smoove IB+ - Space-saving: Motor control unit and operating point combined in one device - Can be mounted in the flush-mounted box or cable duct - Design compatible with the switch programs of various manufacturers - Priority management between local and central commands via different operating modes, adjustable via animeo Building Controller - Wake-up time of electric drives adjustable via animeo Building Controller - Adjustable running and turning time per drive: only minimal dark phases for room users - Limitable Venetian blind turning angle: energy saving and increased lighting comfort Scope of delivery: Motor control unit without frame Operating voltage: 230 V AC Output voltage: 230 V AC Output current: 3.15 A Operating temperature: 0 °C to 45 °C Protection type: IP20 Protection class: II Dimensions (WxHxD): 50 x 50 x 41 mm
