TCS camera module AMI10510-0010, silver, Manufacturer: TCS TürControlSysteme AG, Production: Made in Germany, Article number: AMI10510-0010, PRODUCT FEATURES, Basic features:, Device type: Camera module, Communication technology: TCS:BUS, Mounting type: Flush-mounted installation, can be integrated behind 3 mm front panels, Flush-mounted installation for front panels from 1.5 mm to 2.5 mm using the enclosed spacer plates, Module grid spacing 120 mm, Video, Camera design: Camera module, Electronic shutter speed automatic (AES), Installer interface, Connection to display module / TCS:BUS speech module: AMI10105-0710 / AMI11110-0010, TECHNICAL DATA, Mechanical properties, Dimensions HxWxD (mm): H 105 x W 105 x D 43, Visible front dimensions (cut-out) 82 mm x 82 mm, design: module for outdoor stations with customized configuration, material / color: front panel aluminum anodized silver, camera viewing window acrylic glass, permissible ambient temperature (°C): 10 °C to 50 °C, electrical properties, supply voltage: +24 V 8 % supply and control unit, current consumption, maximum (mA): I (Pmax) = 35 mA, camera properties, resolution (TVL): 380 H TVL Color,, resolution, maximum (pixels x pixels): PAL: 648 H x 488 V, image sensor: 1/4' single-chip CMOS, diagonal detection angle (°): 130° diagonal, light sensitivity (lux): 1.0 lx (f 1.2), lens: 2.0 mm, F=2.5, video output signal: (differential, coaxial): 1.1 Vp-p, number of usable gateways: 4, indoor station line, short circuit detection between: ax-bx, ax-Px, bx-Px, indoor station line, maximum number: 1, SCOPE OF DELIVERY, screwdriver, mounting accessories: '4x fastening nut M4, 3x spacer film 0.5 mm', NOTE, Attention: The camera module must not be exposed to direct sunlight or aligned towards it
| Property | Value |
| Installation technology: | Bus system |
| Color: | black |
| Width: | 105 mm |
| Height: | 105 mm |
| Depth: | 43 mm |
| Design: | Video module |
| With day/night function: | no |
| Camera opening angle: | 90 ° |
| PTZ function (pan/tilt/zoom): | no |
| Manually adjustable camera: | no |
| Image system: | PAL |
