Features: , Dimensions: W = 32 mm, H = 42.6 mm, D = 14 mm , 2x SC-Simplex or 1x SC-RJ (according to IEC 61754-4) can be plugged in on the inside , Installation dimension ø25 mm with anti-twist protection , Color coding: Multimode = beige, Singlemode = blue , Coupling insert can be mounted in 4 x 90° steps , Screw fastening with nut M25x1.5 for wall thicknesses up to 5 mm, alternatively with 4x M3 screw for wall thicknesses greater than 5 mm , Protection class IP67 when not plugged in thanks to integrated protective flap , UV-resistant plastic, fire protection class UL94 V0 , Short name: Flange coupling 2xSC IP67 for singlemode
