Plug-in/print relay 1 changeover contact (AgNi) for 10 A / 250 V AC, contact pin pitch: 3.5 mm coil data: 6 V AC, 1.2 VA, 21 Ohm, relay protection type: RT II - see technical explanations Notes for automatic soldering process
| Property | Value |
| Number of contacts as changeover contact: | 1 |
| Rated control supply voltage Us at AC 50 Hz: | 6 V |
| Rated control supply voltage Us at AC 60 Hz: | 6 V |
| Type of voltage for actuation: | AC |
| Design of the electrical connection: | Plug connection |
| Drive, polarity: | unpolarized |
| Height: | 25 mm |
| Width: | 12.4 mm |
| Depth: | 29 mm |
| Switching behavior of the drive: | monostable |
| Type of switching contact: | Single contact |
| With positively guided contacts: | no |
| With removable terminals: | no |
| Complete device with base: | no |
| Protection class (IP): | IP20 |
| Rated current: | 10 A |
| With LED display: | no |
