Finder 41.52.6.012.4016 bistable print relay 4 coils

In stock

SKU: 272164

Price on request

€5.43

€0

Overview

Low plug-in/print relay, bistable with 2 coil versions - polarized: A3 (+) A2 (-) = SET, A3 (+) A1 (-) =RESET. 2 changeover contacts for 8 A / 250 V AC. Contact material AgSnO2, contact pin pitch: 5.0 mm. Coil data: 12 V DC, 0.65 W, 220 Ohm, ambient temperature -40 to + 85° C. Relay protection class: RT II.

Property	Value
Number of contacts as changeover contacts:	2
Rated control supply voltage Us at DC:	12 V
Type of voltage for actuation:	DC
Design of the electrical connection:	PCB connection
Drive, polarity:	polarized
Height:	15.7 mm
Width:	12.6 mm
Depth:	29 mm
Switching behavior of the drive:	bistable
Type of switching contact:	Single contact
With positively guided contacts:	no
With removable terminals:	no
Complete device with base:	no
Protection class (IP):	IP40
Rated current:	8 A
With LED display:	no
