Finder 72.01.8.240.0000 Level monitoring device

In stock
SKU: 272198
€47.32
Into a basketIn the basketGo

Overview

Level monitoring of conductive liquids, positive safety logic when filling and pumping out, sensitivity adjustable. Double insulation between power supply and contacts. Power supply and probes, contacts and probes. Sensitivity adjustable between 5 and 150 kOhm. Delay times: 0.5 or 7 s. Function (filling or pumping out) selectable via rotary switch on the front. Modular design for 35 mm DIN rails, LED status display, 16 A

Property Value
Number of contacts as changeover contacts: 1
Design of the electrical connection: Screw connection
Max. permissible pick-up delay time: 7 s
Max. permissible release delay time: 7 s
Min. adjustable pick-up delay time: 0.5 s
Min. adjustable release delay time: 0.5 s
Physical measuring principle: conductive
Width: 35 mm
Height: 84 mm
Depth: 58 mm
With removable terminals: no
Number of electrode inputs: 3
Adjustable response sensitivity: yes
Rated control supply voltage Us at AC 50 Hz: 230 V
Rated control supply voltage Us at AC 60 Hz: 230 V
Cascadable: no

Characteristics

ManufacturerFinder
HAN72.01.8.240.0000
GTIN8012823290607
Response sensitivity adjustableYes
Number of contacts as changeover1
Design of the electrical connectionScrew connection
Rated control supply voltage Us at AC 50 Hz230V
Rated control supply voltage Us at AC 60 Hz230V
Width35 mm
Height84 mm
With removable clampsNo
Depth58 mm
