Wago 788-404 3-pin 24VDC relay modules

Wago 788-404 3-pin 24VDC relay modules

In stock

SKU: 519998

Price on request

€16

€0

Into a basketIn the basketGo

Overview

Relay module, nominal input voltage DC 24 V, 1 changeover contact, limiting continuous current 16 A, with gold contacts, status display red, 15 mm width, 2.50 mm², gray

Property	Value
Number of contacts as changeover contacts:	1
Rated control supply voltage Us at DC:	24 V
Type of voltage for actuation:	DC
Design of the electrical connection:	Spring-loaded connection
Drive, polarity:	Poled
Height:	86 mm
Width:	15 mm
Depth:	54 mm
Switching behavior of the drive:	monostable
Type of switching contact:	Single contact
With positively guided contacts:	no
With removable terminals:	no
Complete device with base:	yes
Protection class (IP):	IP20
Rated current:	16 A
With LED display:	yes

Characteristics

Complete device with baseYes

Drive, polarityPolarized

Type of switching contactSingle contact

Switching behavior of the driveMonostable

With positively guided contactsNo

HAB788-404 3-pin 24VDC

Manufacturer

HAN788-404

GTIN4045454352158

Number of contacts as changeover1

Design of the electrical connectionSpring-loaded connection

Rated control supply voltage Us at DC24V

Width15 mm

Height86 mm

With LED displayYes

With removable clampsNo

Rated current16A

IP protection)IP20

Voltage type for actuationDC

Depth54 mm

Wago 788-404 3-pin 24VDC relay modules

Wago 788-404 3-pin 24VDC relay modules

Price on request

€16

€0

Into a basketIn the basketGo
