ABB Stotz-Kontakt CR-S024VDC1R, plug-in interface relay 1We, A1-A2=24VDC, Output=6A/250VAC, 1SVR405501R3010

In stock
SKU: 197187
€4.46
Into a basketIn the basketGo

Overview

As an interface, interface relays connect the electronic control level, for example PLC, with the level of the sensors/actuators. They perform various functions: switching of direct or alternating voltage loads with different ohmic, inductive and capacitive components, switching in the voltage range from a few mV to 250 V, switching in the current range from a few mA to 6 A, amplifying weak control signals, potential separation of control and load circuits and signal multiplication. The CR-S series has 5 different coil voltage ranges with 1 changeover contact, optionally in standard or hard gold-plated version. Two variants are offered: complete variants or freely selectable bases and plug-in relays.

PropertyValue
Number of contacts as changeover contact:1
Rated control supply voltage Us at AC 50 Hz:0.0 V
Rated control supply voltage Us at AC 60 Hz:0.0 V
Rated control supply voltage Us at DC:24 V
Type of voltage for actuation:DC
Design of the electrical connection:Plug connection
Drive, polarity:polarized
Height:15 mm
Width:5 mm
Depth:28 mm
Switching behavior of the drive:monostable
Type of switching contact:single contact
With positively guided contacts:no
With removable terminals:no
Complete device with base:no
Protection class (IP):IP20
Nominal current:6 A
With LED display:no

Characteristics

Complete device with baseNo
Drive, polarityPolarized
Type of switching contactSingle contact
Switching behavior of the driveMonostable
With positively guided contactsNo
HABCR-S024VDC1R
Minimal order10 pieces
ManufacturerABB Stotz-Kontakt
HAN1SVR405501R3010
GTIN4013614499128
Number of contacts as changeover1
Design of the electrical connectionPlug connection
Rated control supply voltage Us at AC 50 Hz0.0V
Rated control supply voltage Us at AC 60 Hz0.0V
Rated control supply voltage Us at DC24V
Width5 mm
Height15 mm
With LED displayNo
With removable clampsNo
Rated current6A
IP protection)IP20
Voltage type for actuationDC
Depth28 mm
ABB Stotz-Kontakt CR-S024VDC1R, plug-in interface relay 1We, A1-A2=24VDC, Output=6A/250VAC, 1SVR405501R3010
ABB Stotz-Kontakt CR-S024VDC1R, plug-in interface relay 1We, A1-A2=24VDC, Output=6A/250VAC, 1SVR405501R3010
