ColorWhite
Bridging switchNo
With signal unitNo
Response brightness5 to 1000 lx
Forced shutdownNo
Max. inrush current10 A
Scanning angle360 °
Forced switching onNo
Max. presence range3 m²
HAN2090200
GTIN4003468200001
Dimming function with dimming insertNo
Alarm functionNo
Connection typeScrew terminal
Response sensitivity adjustableNo
Response brightness adjustableYes
Antibacterial treatmentNo
VersionPresence detector
Surface finishFrosted
Width44 mm
Diameter44 mm
Installation width44 mm
Installation diameter36 mm
Installation depth28 mm
Detection field diameter on floor8m
Detection angle horizontal0 to 360 °
Remote controllableYes
Frequency50 to 60 Hz
Suitable for C-loadNo
Suitable for ceiling mountingYes
Suitable for wall mountingNo
Suitable for wireless transmissionNo
HVAC controlNo
Halogen freeNo
Height43 mm
Constant light controlNo
Max. duty cycle30 min
Max. range frontal4m
Max. range to one side4m
Max. switching capacity2000W
Min. duty cycle30s
With DALI interfaceNo
With remoteNo
Mounting typeFlush-mounted
Extension inputYes
Nominal voltage230V
SurfaceUntreated
Optimal mounting height2.5m
RAL number (similar)9010
Impact resistanceIK04
IP protection)IP40
Sensor typePassive infrared
Voltage typeAC
Teach function for response brightnessYes
Temperature-20 to 50 °C
Depth44 mm
Animal corridorNo
TransparentNo
Staircase monitoringYes
Creep protection/rear field monitoringNo
NetworkableNo
MaterialPlastic
Material qualityThermoplastic
