Turck 6626525 PKW3M-1-RSC4T/TEL Actuator and sensor cable

In stock

SKU: 553643

Price on request

€15.67

€0

Overview

Actuator and sensor cable / PVC, connecting cable, M8 coupling, angled, 3-pin, cable length: 1.0 meter, sheath material: PVC, sheath color: black, chemical and oil resistant, flame retardant, resistant to acids and alkalis, microbe and hydrolysis resistant, LABS-free, approval: cULus, RoHS compliant, protection class IP67, M12 connector, straight, 3-pin

Property	Value
Rated current In:	4 A
Color of the cable sheath:	black
With LED display:	no
Material of the cable sheath:	Polyvinyl chloride (PVC)
Material of the contact base body:	CuZn
Number of poles:	3
Connection field side:	M12
Type of plug contact, field side:	Male (plug)
Cable feed, field side:	straight
Connection, housing side:	M8
Plug housing:	Female (socket)
Cable feed, housing side:	angled
Cable length:	1 m
Shielded:	no
Material of the contact coating:	gold
Permissible external cable temperature after assembly without vibration:	-40 to 105 °C
Permissible external cable temperature during assembly/handling:	-5 to 80 °C
