Weidmüller 1499760000 BLT 5.08/4 SN OR connector

In stock

SKU: 640539

Price on request

€7.25

€0

Overview

Plug-in circuit board connection with innovative connection technology for safe and intuitive handling.

Property	Value
Connectable cable type:	Round cable
Connectable conductor cross-section, single-wire:	0.2 to 2.5 mm²
Connectable conductor cross-section, fine-wire with wire end ferrule:	0.2 to 1.5 mm²
Connectable conductor cross-section, fine-wire without wire end ferrule:	0.2 to 2.5 mm²
Design of the electrical connection:	Screw connection
Rated voltage:	320 V
Rated impulse voltage:	4 kV
Rated current In:	24 A
Operating temperature:	-50 to 100 °C
Flammability class of the insulating material according to UL 94:	V0
Housing color:	orange
Contact design:	socket
With protective conductor:	no
Pitch of connections:	5.08 mm
Pitch of contacts:	5.08 mm
Protection class (IP), mounted:	other
Overvoltage category:	III
Pollution level:	2
Material of contact coating:	tin
Material of housing:	plastic
Material of the insulating body:	Polybutylene terephthalate
Material of the contact:	other copper alloys
Angle of contact/conductor connection:	180° (horizontal)
Type of connection:	flexible printed circuit board connector
Number of poles:	4
Housing coating:	other
