Wieland R1.188.1830.0 SNA4043K-A AC115- 120V (A) monitoring relay

In stock

SKU: 674137

Price on request

€128.27

€0

Overview

Basic device also for lifts EN 81-20/50 and burners EN50156-1, one or two-channel control, automatic reset without reset button monitoring, cross-circuit detection, 3 releases, 1 detector, AC 115-120 V 50-60Hz, screw terminal pluggable

Property	Value
Number of outputs, safety-related, undelayed, contact-based:	3
Suitable for monitoring position switches:	yes
Suitable for monitoring proximity switches:	yes
Evaluation of Inputs:	two-channel
Suitable for monitoring magnetic switches:	yes
With muting function:	no
Mounting rail mounting possible:	yes
Number of outputs, signaling function, undelayed, contact-based:	1
Design:	Basic device
Design of the electrical connection:	Screw connection
Number of outputs, safety-related, undelayed, semiconductor:	3
Suitable for monitoring optoelectronic protective devices:	yes
Suitable for monitoring EMERGENCY STOP circuits:	yes
Width:	22.5 mm
Height:	96.5 mm
With removable terminals:	yes
With start input:	yes
With feedback circuit:	yes
