Wiska 10109066 BMCG-PU-C-21-BL blue NW21 steel protective hose

In stock
SKU: 634338
€24.47
Into a basketIn the basketGo

Overview

Metallic protective hose with PU coating to protect the cables under extreme mechanical stress. This hose is ideally suited for use in rail transport.

Property Value
Nominal diameter: 21 mm
Surface protection: galvanized
Sheathing material 1st layer: Polyurethane (PUR)
Inner diameter: 20.5 mm
Outer diameter: 24.7 mm
Compressive strength: 1250 N
Operating temperature: -45 to 120 °C
Tensile strength: 1000 N
Bending radius, static: 60 mm
Weight: 0.36 kg/m
Color: black
Electrical properties: with conductive properties
Flame-spreading: no
Suitable for Ex area: no
Approval according to FI: no
With approval according to UL: no
Material: steel
Protection class (IP): IP67
Bending behavior: flexible

Characteristics

Inner diameter20.5 mm
Bending radius, static60 mm
Bending behaviorFlexibel
Flame propagatingNo
HABBMCG-PU-C-21-BL blue NW21
ManufacturerWiska
HAN10109066
GTIN4007686080230
Outer diameter24.7 mm
Operating temperature-45 to 120 °C
ColorBlack
Weight0.36 kg/m
Nominal diameter21 mm
Surface protectionGalvanized
IP protection)IP67
MaterialSteel
Wiska 10109066 BMCG-PU-C-21-BL blue NW21 steel protective hose
