Frame 5-way, vertical and horizontal installation, LS 990, aluminum Frame 5-way, aluminum
for horizontal and vertical combination
With sealing flange item no.: 551 WU, protection level IP 44 is guaranteed.
Material: aluminum AlMg1 natural tone, matt stained
Dimensions (W x H): 81 x 365 mm
| Property | Value |
| Height: | 365 mm |
| Width: | 81 mm |
| Material: | Metal |
| Installation direction: | horizontal and vertical |
| Number of units: | 5 |
| Color: | Aluminum |
| Protection class (IP): | IP44 |
| Suitable for built-in installation: | yes |
| Halogen-free: | yes |
| With hinged lid: | no |
| Text field/labeling area: | no |
| Depth: | 11 mm |
| Suitable for device installation duct: | yes |
| Material quality: | aluminium |
| Surface: | anodized |
| Surface finish: | matt |
| Number of units horizontal: | 1 |
| Number of units vertical: | 5 |
| Mounting type: | other |
| Installation width: | 70 mm |
| Installation height: | 70 mm |
| Transparent: | no |
| With mounting frame: | no |
