Jung PLF1D05AL-L LED floodlight Plug & Light, 2,700 K, aluminium

In stock
SKU: 405098
€72.07
Into a basketIn the basketGo

Overview

LED floodlight Plug & Light, 2,700 K, aluminum Intended use
Dimmable light attachment for indoor lighting
Installation by plugging into the light socket of the Plug & Light system

Product features
Accent light or work light
Dimming with a suitable LED dimmer at a constant color temperature of 2700 K
Glare-free, asymmetrical optics
Flicker-free light across the entire dimming range
Light attachment can be changed during operation
Can be rotated continuously by 360°
Nominal voltage: DC 12 V SELV
Power consumption: 4.1 W
Connection type: electrical coupling via gold-plated sliding contacts
Protection class: III
Dimensions (W x H x D): 70 x 70 x 17 mm
Luminous flux: 290 lm
Color temperature: 2,700 K
Color rendering index: typ. 90
Beam angle: asymmetrical light distribution
Energy efficiency class: G
This luminaire contains permanently installed LED lamps that cannot be replaced.

Property Value
Max. System power: 4.8 W
Rated luminous flux according to IEC 62722-2-1: 290 lm
Suitable for number of lamps: 1
Nominal voltage: 12 V
Housing color: Aluminum
Housing material: Plastic
Color temperature: 2700 K
Suitable for ceiling mounting: yes
Suitable for wall mounting: yes
Voltage type: DC
With motion detector: no
With light source: yes
Light source: LED not replaceable
Rated ambient temperature according to IEC62722-2-1: 5.0 to 25.0 °C
Connection type: other
Cover material: other
Without dimming function: no
Light distribution: asymmetrical
With light sensor: no
Suitable for recessed mounting: no
Light color: white
Suitable for light strip configuration: no
Suitable for pendulum suspension: no
Suitable for surface mounting: no
Suitable for emergency lighting: no
With air slots: no
DALI dimming: no

Characteristics

ManufacturerJung
HANPLF1D05AL-L
GTIN4011377174634
Connection typeOther
Rated luminous flux according to IEC 62722-2-1290lm
Rated ambient temperature according to IEC62722-2-15.0 to 25.0 °C
Dimming DALINo
Color temperature2700K
Suitable for surface mountingNo
Suitable for ceiling mountingYes
Suitable for flush mountingNo
Suitable for number of lamps1
Suitable for light strip configurationNo
Suitable for emergency lightingNo
Suitable for pendulum suspensionNo
Suitable for wall mountingYes
Housing colorAluminum
LampsLED not replaceable
Light colorWhite
Light distributionAsymmetrical
Max. system performance4.8W
With motion detectorNo
With light sourceYes
With light sensorNo
With air slotsNo
Nominal voltage12V
Without dimming functionNo
Voltage typeDC
Cover materialOther
Housing materialPlastic
