Siedle In-Home bus video indoor stations, AS/A series, black for the AS and A series including button set and labelling foil without frame The modules of the indoor station can be combined with multiple frames (horizontal or vertical). Remote installation in separate frames and installation in surface-mounted caps is possible. An additional power supply is required to operate the video indoor station. Recommendation: NG 706-30/33-0 from Siedle (see Siedle planning manual). Product features TFT color monitor Screen diagonal 55 mm (2.2'') 320 x 240 pixels Settings for brightness and color Includes video connection cable (black, 220 mm) Calling, speaking, seeing, door opening, light, storey call, switching/control functions and internal communication Reverse polarity protected 2-wire installation, 2-pole additional power supply required (JY(St)Y 2 x 2 x 0.8) Automatic video connection when door call is made Speech button with green status LED Light, call silencing, monitor and function buttons freely configurable. Button functions can be activated without additional installation, e.g. for internal telephony, activation of switching/control functions in conjunction with Siedle bus switching module BSM/BSE 650-.., targeted selection of door loudspeakers (outdoor stations)/cameras A switching function (in conjunction with Siedle bus switching module BSM/BSE 650-..) can be configured on the door opener button using BPS. Integrated listening and viewing lock Parallel connection (simultaneous calling) of max. 16 video indoor stations (from the 3rd device onwards, the Siedle BPS is required for programming.) Speech/video connection possible at any time, even without a door call High-quality sound and great speaker dynamics Electret condenser microphone Connection for Siedle In-Home bus Connection for floor call button Call generator with 11 ringtone melodies, Incl. gong Ringtone volume adjustable in 5 levels up to 92 dB(A) Speech volume adjustable in 5 levels Programming manually, plug+play and via Siedle bus programming software (BPS), in accordance with Siedle system manual Indoor station with hands-free operation Status display when speech connection is active Call silencing with status display Call differentiation for storey calls, 2 door calls and internal calls Door opener/light function at any time via bus line Door call pickup Group formation for door calls. Each indoor station can belong to up to 4 groups on the same line Intercom functions:- Call forwarding- Internal group call- Collective announcement- Automatic call acceptance for internal calls- Doormatic 5 LEDs for display (e.g. door open) without additional wiring Display of operational readiness via an LED Optical call display by flashing LED on the talk button Illuminated label field Includes label foils with symbols for audio and video Includes audio connection cable (red, 220 mm) Connection for additional power supply (required for operating a video module, lighting the label field in the universal touch module and when connecting a second touch module.) Connection for another touch module (standard or universal, max. 2 touch modules per indoor station)
