Brumberg 10159073 white 1.5W 130lm 3000K LED recessed wall light

Brumberg 10159073 white 1.5W 130lm 3000K LED recessed wall light

In stock

SKU: 814072

Price on request

€84.16

€0

Overview

LED recessed wall light, for device boxes, white, square. Recessed mounting, wall mounting. For installation in hollow wall or concrete device boxes with an installation depth of at least 62 mm (screw spacing: 60 mm). Compatible with Kaiser device boxes for hollow wall installation, item no. 9064-02 or 9464-02, or concrete installation, item no. 1556-04. Attention: Delivery is WITHOUT device box. Mounting type: built-in mounting, mounting location: wall mounting, material: aluminum / steel / glass / plastic, protection class on the room side: according to DIN EN 60529: IP20, protection class: (EN 61140) I, voltage: 230V AC 50Hz, power: 1.5W, number of lamps / sockets: 1.0 pcs, luminous flux: 35lm, color temperature: 3,000 K, light color: white, with operating device, type of dimming: switchable.

Property	Value
Max. System power:	1.5 W
Rated luminous flux according to IEC 62722-2-1:	35 lm
Suitable for number of lamps:	1
Length:	78 mm
Width:	78 mm
Height/depth:	9 mm
Protection rating (IP):	IP20
Protection class:	I
Nominal voltage:	230 V
Housing color:	white
Housing material:	Aluminum
Color temperature:	3000 K
Color rendering index CRI:	90-100
Suitable for ceiling mounting:	no
Suitable for wall mounting:	yes
Voltage type:	AC
With motion detector:	no
With light source:	yes
Light source:	LED not replaceable
With operating device:	yes
Cover material:	opal glass
Installation height/depth:	65 mm
Without dimming function:	yes
Light distribution:	asymmetrical
Operating device:	LED operating device, current-controlled
Suitable for recessed mounting:	yes
Suitable for light strip configuration:	no
Suitable for pendant suspension:	no
Suitable for surface mounting:	no
Installation diameter:	68 mm
Covering of the lamp with thermal insulation material possible:	no
Dimming DMX:	no
Dimming DSI:	no
Dimming LineSwitch:	no
Dimming potentiometer (device-integrated):	no
Dimming 0-10 V:	no
Dimming GPRS:	no
Dimming 1-10 V:	no
Dimming manufacturer-specific:	no
Dimming DALI:	no
Dimming mains voltage modulation:	no
Dimming trailing edge:	no
Dimming leading edge:	no
Dimming programmable:	no
Dimming RF:	no
Dimming Sine Wave Reduction:	no
Dimming Touch and Dim:	no
Dimming Zigbee:	no
Dimming with Push button:	no
Dimming depending on the operating device:	no
Rated service life L70/B50 at 25 °C:	50000 h
Suitable for lamp power:	1.5 W
Luminaire luminous efficacy:	23.33 lm/W

Characteristics

HABWhite 1.5W 130lm 3000K

Manufacturer

HAN10159073

GTIN4251433925668

Covering the luminaire with thermal insulation material possibleNo

Rated lifetime L70/B50 at 25 °C50000 hours

Rated luminous flux according to IEC 62722-2-135lm

Operating deviceLED control gear current controlled

Width78 mm

Dimming 0-10 VNo

Dimming 1-10 VNo

Dimming DALINo

Dimming DMXNo

Dimming DSINo

Dimming GPRSNo

Dimming LineSwitchNo

Dimming mains voltage modulationNo

Dimming trailing edgeNo

Dimming phase controlNo

Dimming potentiometer (integrated)No

Dimming RFNo

Dimming Sine Wave ReductionNo

Dimming Touch and DimNo

Dimming ZigbeeNo

Dimming depends on the control gearNo

Dimming manufacturer-specificNo

Dimming with push buttonNo

Dimming programmableNo

Installation diameter68 mm

Installation height/depth65 mm

Color temperature3000K

Color rendering index CRI90-100

Suitable for surface mountingNo

Suitable for ceiling mountingNo

Suitable for flush mountingYes

Suitable for lamp power1.5W

Suitable for number of lamps1

Suitable for light strip configurationNo

Suitable for pendulum suspensionNo

Suitable for wall mountingYes

Housing colorWhite

Height/Depth9 mm

Luminaire luminous efficacy23.33lm/W

LampsLED not replaceable

Light distributionAsymmetrical

Length78 mm

Max. system performance1.5W

With operating deviceYes

With motion detectorNo

With light sourceYes

Nominal voltage230V

Without dimming functionYes

IP protection)IP20

Protection classI

Voltage typeAC

Cover materialGlass opal

Housing materialAluminum
