Brumberg 88398174 32W 4000K ws DA LED track spotlight

Brumberg 88398174 32W 4000K ws DA LED track spotlight

In stock

SKU: 872688

Price on request

€180.22

€0

Overview

LED track spotlight, structured white, round. Track mounting, ceiling mounting, heat dissipation: passive (without fan), including control gear, switchable, (230 V AC 50 Hz). Light including Euro adapter for standard 3-phase rails. Installation type: track mounting, installation location: ceiling mounting, material: aluminum, protection class on the room side: according to DIN EN 60529: IP20, protection class: (EN 61140) I, voltage: 230V AC 50Hz, power: 32W, number of lamps / sockets: 1.0 pcs, color temperature: 4,000 K, light color: white, beam angle: 30°, adjustability: rotatable and head adjustable, with control gear, type of dimming: DALI.

Property	Value
Max. System power:	32 W
Housing color:	white
Housing material:	aluminum
Protection class (IP):	IP20
Light source:	LED not replaceable
Protection class:	I
With light source:	yes
With operating device:	yes
Suitable for recessed mounting:	no
Length:	235 mm
Height/depth:	263 mm
With motion detector:	no
Color temperature:	4000 K
Nominal voltage:	230 V
Suitable for lamp power:	32 W
Beam angle:	medium beam 21-40°
Color rendering index CRI:	90-100
Suitable for ceiling mounting:	yes
Light distribution:	symmetrical
Operating device:	LED operating device current-controlled
Reflector:	high gloss
Suitable for number of bulbs:	1
Voltage type:	AC
Light color:	white
Suitable for track mounting:	yes
Suitable for clamp mounting:	yes
Suitable for pendulum suspension:	no
Suitable for pedestal/floor mounting:	no
Suitable for truss mounting:	no
With Light sensor:	no
Suitable for surface mounting:	yes
Suitable for cable system:	no
Brushed surface:	no
Dimming depending on operating device:	no
Dimming 0-10 V:	no
Dimming 1-10 V:	no
Dimming DALI:	yes
Dimming DMX:	no
Dimming DSI:	no
Dimming potentiometer (device integrated):	no
Dimming GPRS:	no
Dimming LineSwitch:	no
Dimming manufacturer-specific:	no
Dimming mains voltage modulation:	no
Dimming trailing edge:	no
Dimming leading edge:	no
Dimming programmable:	no
Dimming RF:	no
Dimming Sine Wave Reduction:	no
Dimming Touch and Dim:	no
Dimming Zigbee:	no
Dimming with push button:	no
Without dimming function:	no
Type of wiring:	Termination

Characteristics

HAB32W 4000K white DA

Manufacturer

HAN88398174

GTIN4251433944232

Type of wiringDiploma

Beam angleMedium beam 21-40°

Operating deviceLED control gear current controlled

Dimming 0-10 VNo

Dimming 1-10 VNo

Dimming DALIYes

Dimming DMXNo

Dimming DSINo

Dimming GPRSNo

Dimming LineSwitchNo

Dimming mains voltage modulationNo

Dimming trailing edgeNo

Dimming phase controlNo

Dimming potentiometer (integrated)No

Dimming RFNo

Dimming Sine Wave ReductionNo

Dimming Touch and DimNo

Dimming ZigbeeNo

Dimming depends on the control gearNo

Dimming manufacturer-specificNo

Dimming with push buttonNo

Dimming programmableNo

Color temperature4000K

Color rendering index CRI90-100

Suitable for surface mountingYes

Suitable for ceiling mountingYes

Suitable for flush mountingNo

Suitable for clamp mountingYes

Suitable for lamp power32W

Suitable for number of lamps1

Suitable for pendulum suspensionNo

Suitable for podium/floor mountingNo

Suitable for rope systemNo

Suitable for busbar mountingYes

Suitable for truss mountingNo

Housing colorWhite

Height/Depth263 mm

LampsLED not replaceable

Light colorWhite

Light distributionSymmetrical

Length235 mm

Max. system performance32W

With operating deviceYes

With motion detectorNo

With light sourceYes

With light sensorNo

Nominal voltage230V

Brushed surfaceNo

Without dimming functionNo

ReflectorHigh gloss

IP protection)IP20

Protection classI

Voltage typeAC

Housing materialAluminum
