HAN12287153
GTIN4251433906155
Covering the luminaire with thermal insulation material possibleNo
Beam angleMedium beam 21-40°
Rated luminous flux according to IEC 62722-2-1510lm
Operating deviceLED control gear current controlled
Suitable for computer workstations according to EN 12464-1Yes
Width95 mm
Dimming 0-10 VNo
Dimming 1-10 VNo
Dimming DALINo
Dimming DMXNo
Dimming DSINo
Dimming GPRSNo
Dimming LineSwitchNo
Dimming mains voltage modulationNo
Dimming trailing edgeNo
Dimming phase controlNo
Dimming potentiometer (integrated)No
Dimming RFNo
Dimming Sine Wave ReductionNo
Dimming Touch and DimNo
Dimming ZigbeeNo
Dimming depends on the control gearNo
Dimming manufacturer-specificNo
Dimming with push buttonNo
Dimming programmableNo
Installation height/depth48 mm
Color temperature3000K
Color rendering index CRI80-89
VersionOther
Suitable for surface mountingNo
Suitable for ceiling mountingYes
Suitable for flush mountingYes
Suitable for clamp mountingNo
Suitable for lamp power6W
Suitable for number of lamps1
Suitable for pendulum suspensionNo
Suitable for podium/floor mountingNo
Suitable for rope systemNo
Suitable for busbar mountingNo
Suitable for truss mountingNo
Housing colorNickel
Height/Depth3 mm
LED nominal current at constant current350mA
Luminaire luminous efficacy85lm/W
LampsLED not replaceable
Light emissionDirect
Light colorWhite
Luminous flux510lm
Light distributionSymmetrical
Length95 mm
Max. system performance6W
With operating deviceNo
With motion detectorNo
With light sourceYes
With light sensorNo
Brushed surfaceNo
Without dimming functionNo
ReflectorHigh gloss
Protection classIII
Voltage typeDC
AdjustabilityRotatable and pivotable
Cover materialPlastic transparent
Housing materialAluminum
