HAN12417173
GTIN4251433916024
Covering the luminaire with thermal insulation material possibleNo
Beam angleMedium beam 21-40°
Outer diameter105 mm
Rated luminous flux according to IEC 62722-2-1700lm
Operating deviceLED control gear current controlled
Dimming 0-10 VNo
Dimming 1-10 VNo
Dimming DALINo
Dimming DMXNo
Dimming DSINo
Dimming GPRSNo
Dimming LineSwitchNo
Dimming mains voltage modulationNo
Dimming trailing edgeNo
Dimming phase controlNo
Dimming potentiometer (integrated)No
Dimming RFNo
Dimming Sine Wave ReductionNo
Dimming Touch and DimNo
Dimming ZigbeeNo
Dimming depends on the control gearNo
Dimming manufacturer-specificNo
Dimming with push buttonNo
Dimming programmableNo
Installation height/depth60 mm
Color temperature3000K
Color rendering index CRI90-100
Suitable for surface mountingNo
Suitable for ceiling mountingYes
Suitable for flush mountingYes
Suitable for clamp mountingNo
Suitable for lamp power9.3W
Suitable for number of lamps1
Suitable for pendulum suspensionNo
Suitable for podium/floor mountingNo
Suitable for rope systemNo
Suitable for busbar mountingNo
Suitable for truss mountingNo
Housing colorWhite
Height/Depth3 mm
LED nominal current at constant current500mA
Luminaire luminous efficacy75.27lm/W
LampsLED not replaceable
Light emissionDirect
Light colorWhite
Luminous flux700lm
Light distributionSymmetrical
With operating deviceNo
With motion detectorNo
With light sourceYes
With light sensorNo
Brushed surfaceNo
Without dimming functionNo
ReflectorHigh gloss
IP protection)IP20
Protection classIII
Voltage typeDC
AdjustabilityRotatable and pivotable
Cover materialPlastic transparent
Housing materialAluminum
