HAN12491073
GTIN4251433914426
Covering the luminaire with thermal insulation material possibleNo
Beam angleMedium beam 21-40°
Outer diameter110 mm
Rated luminous flux according to IEC 62722-2-1880lm
Operating deviceLED control gear current controlled
Dimming 0-10 VNo
Dimming 1-10 VNo
Dimming DALINo
Dimming DMXNo
Dimming DSINo
Dimming GPRSNo
Dimming LineSwitchNo
Dimming mains voltage modulationNo
Dimming trailing edgeNo
Dimming phase controlNo
Dimming potentiometer (integrated)No
Dimming RFNo
Dimming Sine Wave ReductionNo
Dimming Touch and DimNo
Dimming ZigbeeNo
Dimming depends on the control gearNo
Dimming manufacturer-specificNo
Dimming with push buttonNo
Dimming programmableNo
Installation height/depth60 mm
Color temperature1800 to 3000 K
Color rendering index CRI80-89
VersionOther
Suitable for surface mountingNo
Suitable for ceiling mountingYes
Suitable for flush mountingYes
Suitable for clamp mountingNo
Suitable for lamp power12W
Suitable for number of lamps1
Suitable for pendulum suspensionNo
Suitable for podium/floor mountingNo
Suitable for rope systemNo
Suitable for busbar mountingNo
Suitable for truss mountingNo
Housing colorWhite
Height/Depth3 mm
LED nominal current at constant current350mA
Luminaire luminous efficacy73.33lm/W
LampsLED not replaceable
Light emissionDirect
Light colorWhite
Luminous flux880lm
Light distributionSymmetrical
With operating deviceNo
With motion detectorNo
With light sourceYes
With light sensorNo
Brushed surfaceNo
Without dimming functionNo
ReflectorHigh gloss
IP protection)IP20
Protection classIII
Voltage typeDC
AdjustabilitySwiveling
Cover materialGlass transparent
Housing materialAluminum
