HAN12642073
GTIN4251433916147
Covering the luminaire with thermal insulation material possibleNo
Beam angleMedium beam 21-40°
Rated luminous flux according to IEC 62722-2-1950lm
Operating deviceLED control gear current controlled
Width68 mm
Dimming 0-10 VNo
Dimming 1-10 VNo
Dimming DALINo
Dimming DMXNo
Dimming DSINo
Dimming GPRSNo
Dimming LineSwitchNo
Dimming mains voltage modulationNo
Dimming trailing edgeNo
Dimming phase controlNo
Dimming potentiometer (integrated)No
Dimming RFNo
Dimming Sine Wave ReductionNo
Dimming Touch and DimNo
Dimming ZigbeeNo
Dimming depends on the control gearNo
Dimming manufacturer-specificNo
Dimming with push buttonNo
Dimming programmableNo
Installation height/depth96 mm
Color temperature3000K
Color rendering index CRI90-100
Suitable for surface mountingNo
Suitable for ceiling mountingYes
Suitable for flush mountingYes
Suitable for clamp mountingNo
Suitable for lamp power8.9W
Suitable for number of lamps1
Suitable for pendulum suspensionNo
Suitable for podium/floor mountingNo
Suitable for rope systemNo
Suitable for busbar mountingNo
Suitable for truss mountingNo
Housing colorWhite
LED nominal current at constant current500mA
Luminaire luminous efficacy106.74lm/W
LampsLED not replaceable
Light emissionDirect
Light colorWhite
Luminous flux950lm
Light distributionSymmetrical
Length68 mm
Max. system performance8.9W
With operating deviceNo
With motion detectorNo
With light sourceYes
With light sensorNo
Brushed surfaceNo
Without dimming functionNo
ReflectorHigh gloss
IP protection)IP20
Protection classIII
Voltage typeDC
AdjustabilityRotatable and pivotable
Cover materialPlastic transparent
Housing materialAluminum
