EVN 487001N round. white IP54 GX53 wall light

In stock

SKU: 810326

Price on request

€47.08

€0

Overview

The surface-mounted light for wall and ceiling mounting can be used both indoors and outdoors. Effect lighting, room lighting, accent lighting and much more can be implemented with this light. The high-voltage socket means that different lamps can be used in the light for a wide range of lighting requirements, meaning there are almost no limits to the design options. Since the light can be connected directly to the 230V supply line, there are no additional costs for operating devices. Only lamps up to a maximum of 11W, but not halogen lamps, can be used in the light.

Property	Value
Number of LM:	1
Height/Depth:	63 mm
Protection rating (IP):	IP54
Protection class:	I
Luminaire with limited surface temperature D-mark according to EN 60598-2-24:	no
Nominal voltage:	220 to 240 V
Housing colour:	white
Material of Housing:	Aluminium
Impact resistance:	IK05
Suitable for ceiling mounting:	yes
Outer diameter:	108 mm
Voltage type:	AC
With motion detector:	no
With light source:	no
Socket:	GX53
Connection type:	Screw terminal
With operating device:	no
Cover material:	opal glass
Without Dimming function:	no
Light emission:	direct
With light sensor:	no
Operating device:	not required
Suitable for recessed mounting:	no
Suitable for computer workstations in accordance with EN 12464-1:	no
Suitable for light strip configuration:	no
Suitable for pendant suspension:	no
Suitable for surface mounting:	yes
Suitable for emergency lighting:	no
Design of the Grid:	without
Covering the light with thermal insulation material possible:	no
Dimming DMX:	no
Dimming DSI:	no
With air slots:	no
Dimming LineSwitch:	no
Dimming Potentiometer (integrated in the device):	no
Dimming 0-10 V:	no
Dimming 1-10 V:	no
Dimming manufacturer-specific:	no
DALI dimming:	no
Mains voltage modulation dimming:	no
Trailing edge dimming:	no
Leading edge dimming:	no
Programmable dimming:	no
RF dimming:	no
Sine wave reduction dimming:	no
Touch and dim dimming:	no
Zigbee dimming:	no
Dimming with Push button:	no
Suitable for lamp power:	0.1 to 11 W
Type of wiring:	suitable for through wiring
Number of poles:	3
Surface protection housing:	powder-coated
Replaceable operating device:	no
DALI-2 dimming:	no
Integrated emergency power supply:	no
Constant luminous flux control:	no
Operation via Bluetooth:	no
Compatible with Apple HomeKit:	no
Compatible with Google Assistant:	no
Compatible with Amazon Alexa:	no
IFTTT support available:	no

Characteristics

Number of LM1

HABRound. white IP54 GX53

Manufacturer

HAN487001N

GTIN4037293014526

Covering the luminaire with thermal insulation material possibleNo

Connection typeScrew terminal

Type of wiringSuitable for through wiring

Execution of the gridWithout

Replaceable operating deviceNo

Outer diameter108 mm

Operation via BluetoothNo

Operating deviceNot required

Suitable for computer workstations according to EN 12464-1No

Dimming 0-10 VNo

Dimming 1-10 VNo

Dimming DALINo

Dimming DALI-2No

Dimming DMXNo

Dimming DSINo

Dimming LineSwitchNo

Dimming mains voltage modulationNo

Dimming trailing edgeNo

Dimming phase controlNo

Dimming potentiometer (integrated)No

Dimming RFNo

Dimming Sine Wave ReductionNo

Dimming Touch and DimNo

Dimming ZigbeeNo

Dimming manufacturer-specificNo

Dimming with push buttonNo

Dimming programmableNo

VersionGX53

Suitable for surface mountingYes

Suitable for ceiling mountingYes

Suitable for flush mountingNo

Suitable for lamp power0.1 to 11W

Suitable for light strip configurationNo

Suitable for emergency lightingNo

Suitable for pendulum suspensionNo

Housing colorWhite

Height/Depth63 mm

IFTTT support availableNo

Compatible with Amazon AlexaNo

Compatible with Apple HomeKitNo

Compatible with Google AssistantNo

Constant luminous flux controlNo

Luminaire with limited surface temperature D-mark according to EN 60598-2-24No

Light emissionDirect

With operating deviceNo

With motion detectorNo

With light sourceNo

With light sensorNo

With air slotsNo

Nominal voltage220 to 240 V

Emergency power supply integratedNo

Surface protection housingPowder coated

Without dimming functionNo

Number of poles3

Impact resistanceIK05

IP protection)IP54

Protection classI

Voltage typeAC

Cover materialGlass opal

Housing materialAluminum
