NIKO 25471 Swiss Garde Hocus Pocus Presence DA, 16m

NIKO 25471 Swiss Garde Hocus Pocus Presence DA, 16m

In stock

SKU: 238159

Price on request

€78.41

€0

Overview

Presence built-in detector for ceiling mounting, Züblin Swiss Garde Hokuspokus presence DA (box cover) white, 2 PIR sensors with elliptical 360° detection area, range approx. 5m presence, approx. 14m length/8m width at 3m height, mounting height approx. 2-5 meters, IP54 splash-proof, class II, 1x relay light channel, configuration via remote control or APP

Property	Value
Depth:	63 mm
Width:	105 mm
Height:	105 mm
Version:	Presence detector
Color:	white
Nominal voltage:	230 V
RAL number (similar):	9010
Material:	Plastic
Mounting type:	Flush-mounted
Response brightness:	5 to 2000 lx
Protection class (IP):	IP54
Max. switching capacity:	2300 W
Voltage type:	AC
Max. range to one side:	4 m
Scan angle:	360 °
Suitable for wall mounting:	no
Min. duty cycle:	10 s
Max. Duty cycle:	20 min
Creep-under protection/rear field monitoring:	no
Temperature:	-20 to 40 °C
Adjustable response brightness:	yes
Adjustable response sensitivity:	yes
Max. presence area:	88 m²
Max. frontal range:	7 m
Max. Inrush current:	10 A
Sensor type:	passive infrared
Optimal installation height:	3 m
Surface finish:	matt
Surface:	untreated
Material quality:	thermoplastic
Detection field diameter on floor:	14 m
Number of switching zones:	1
Detection angle horizontal:	0 to 360 °
Frequency:	50 Hz
Halogen-free:	yes
Constant light control:	no
HVAC control:	no
Forced shutdown:	yes
Networkable:	no
Remote control:	yes
With signal unit:	no
Alarm function:	no
Teach function for response brightness:	yes
Transparent:	no
With Remote control:	yes
Suitable for C-load:	yes
With DALI interface:	no
Extension input:	no
Forced switching on:	yes
Suitable for ceiling mounting:	yes
Connection type:	Plug-in terminal
Antibacterial treatment:	yes
Min. Inrush current:	5 A
Diameter:	105 mm
Installation width:	30 mm
Installation depth:	38 mm
Installation length:	30 mm
Installation diameter:	30 mm
Min. depth of device box:	38 mm

Characteristics

With signal unitNo

Number of switching zones1

Response brightness5 to 2000 lx

Forced shutdownYes

Max. inrush current10 A

Scanning angle360 °

Forced switching onYes

Max. presence range88 m²

Manufacturer

HAN25471

GTIN3505100254713

Alarm functionNo

Connection typePlug-in terminal

Response sensitivity adjustableYes

Response brightness adjustableYes

Antibacterial treatmentYes

VersionPresence detector

Surface finishFrosted

Width105 mm

Diameter105 mm

Installation width30 mm

Installation diameter30 mm

Installation length30 mm

Installation depth38 mm

Detection field diameter on floor14m

Detection angle horizontal0 to 360 °

Color

Remote controllableYes

Frequency50Hz

Suitable for C-loadYes

Suitable for ceiling mountingYes

Suitable for wall mountingNo

HVAC controlNo

Halogen freeYes

Height105 mm

Constant light controlNo

Max. duty cycle20 min

Max. range frontal7m

Max. range to one side4m

Max. switching capacity2300W

Min. duty cycle10s

Min. depth of the device box38 mm

With DALI interfaceNo

With remoteYes

Mounting typeFlush-mounted

Extension inputNo

Nominal voltage230V

SurfaceUntreated

Optimal mounting height3m

RAL number (similar)9010

IP protection)IP54

Sensor typePassive infrared

Voltage typeAC

Teach function for response brightnessYes

Temperature-20 to 40 °C

Depth63 mm

TransparentNo

Creep protection/rear field monitoringNo

NetworkableNo

MaterialPlastic

Material qualityThermoplastic
