Norka 3196803402 PHALANx 620 6900lm room beam LED ceiling light

Norka 3196803402 PHALANx 620 6900lm room beam LED ceiling light

In stock

SKU: 634463

Price on request

€1,071.87

€0

Overview

Extremely impact-resistant anti-vandal light with LEDs. Vandal-proof up to 150 joules/IK 10+. Light housing made of cast aluminum, powder-coated RAL 7016. Short sealing system made of age-resistant, dimensionally stable silicone/synthetic rubber. 4 mm thick light cover with internal aluminum reflector. Built-in operating device. Ready for connection via two rear cable membranes M20. Installation via four rear, concealed mounting holes.

Property	Value
System power:	54 W
Luminous flux:	4023 lm
Number of LM:	1
Length:	620 mm
Width:	620 mm
Height/depth:	128 mm
Protection rating (IP):	IP65
Protection class:	II
Luminaire with limited surface temperature D-mark according to EN 60598-2-24:	yes
Nominal voltage:	230 to 240 V
Housing color:	anthracite
Housing material:	aluminum
Color temperature:	4000 K
Impact resistance:	> IK10
Color rendering index CRI:	80-89
Suitable for ceiling mounting:	yes
Outer diameter:	620 mm
Voltage type:	AC/DC
With motion detector:	no
Beam angle:	medium beam 21-40°
With light source:	yes
Light source:	LED not replaceable
Temperature:	-40 to 40 °C
Connection type:	other
With operating device:	yes
Cover material:	Plastic opal
Light distributor:	Reflector
Without Dimming function:	yes
Light emission:	direct
Light distribution:	asymmetrical
With light sensor:	no
Operating device:	LED operating device, current-controlled
Suitable for recessed mounting:	no
Light color:	white
Suitable for computer workstations in accordance with EN 12464-1:	no
Suitable for light strip configuration:	no
Suitable for pendant suspension:	no
Suitable for Surface mounting:	yes
Suitable for emergency lighting:	yes
Design of the grid:	without
Covering of the luminaire with thermal insulation material possible:	no
Dimming DMX:	no
Dimming DSI:	no
With air slots:	no
Dimming LineSwitch:	no
Dimming Potentiometer (integrated in the device):	no
Dimming 0-10 V:	no
Dimming 1-10 V:	no
Dimming manufacturer-specific:	no
Dimming DALI:	no
Dimming mains voltage modulation:	no
Dimming trailing edge:	no
Dimming leading edge:	no
Dimming programmable:	no
Dimming RF:	no
Dimming Sine Wave Reduction:	no
Dimming Touch and Dim:	no
Dimming Zigbee:	no
Dimming with push button:	no
Glow wire test according to IEC 60695-2-11:	650 °C - 30 s
Suitable for lamp power:	51 W
Luminaire luminous efficacy:	59 lm/W
Power factor:	0.98
Type of wiring:	Termination
Surface protection housing:	powder-coated
Nominal current:	235 mA
Replaceable Operating device:	yes
DALI-2 dimming:	no
Color consistency (McAdam ellipse):	SDCM3
Luminous flux maintenance for average usage time of 50,000 hours at 25 °C ambient temp.:	80 %
Luminous flux maintenance for average usage time of 75,000 hours at 25 °C ambient temp.:	80 %
Failure rate for average usage time of 35,000 hours at 25 °C ambient temp. (tq):	3.5 %
Failure rate for average usage time of Service life of 50,000 hours at 25 °C ambient temp. (tq):	5 %
Failure rate for average service life of 75,000 hours at 25 °C ambient temp. (tq):	7.5 %
Max. number of luminaires circuit breaker B16:	22
Max. Number of lights Circuit breaker C16:	36
Integrated emergency power supply:	no
Constant luminous flux control:	no
Photobiological safety according to EN 62471:	RG1
Glare limitation (UGR):	21
Adjustable color temperature:	no
Adjustable luminous flux:	no
Adjustable beam angle:	no
Operation via Bluetooth:	no
Compatible with Apple HomeKit:	no
Compatible with Google Assistant:	no
Compatible with Amazon Alexa:	no
IFTTT support available:	no

Characteristics

Number of LM1

HABPHALANx 620 6900lm room beam

Manufacturer

HAN3196803402

GTIN4050018033725

Covering the luminaire with thermal insulation material possibleNo

Connection typeOther

Type of wiringDiploma

Execution of the gridWithout

Beam angleMedium beam 21-40°

Beam angle adjustableNo

Replaceable operating deviceYes

Outer diameter620 mm

Operation via BluetoothNo

Operating deviceLED control gear current controlled

Suitable for computer workstations according to EN 12464-1No

Glare limitation (UGR)21

Width620 mm

Dimming 0-10 VNo

Dimming 1-10 VNo

Dimming DALINo

Dimming DALI-2No

Dimming DMXNo

Dimming DSINo

Dimming LineSwitchNo

Dimming mains voltage modulationNo

Dimming trailing edgeNo

Dimming phase controlNo

Dimming potentiometer (integrated)No

Dimming RFNo

Dimming Sine Wave ReductionNo

Dimming Touch and DimNo

Dimming ZigbeeNo

Dimming manufacturer-specificNo

Dimming with push buttonNo

Dimming programmableNo

Color consistency (McAdam ellipse)SDCM3

Color temperature4000K

Color temperature adjustableNo

Color rendering index CRI80-89

Suitable for surface mountingYes

Suitable for ceiling mountingYes

Suitable for flush mountingNo

Suitable for lamp power51 W

Suitable for light strip configurationNo

Suitable for emergency lightingYes

Suitable for pendulum suspensionNo

Housing colorAnthracite

Glow wire test according to IEC 60695-2-11650 °C - 30 s

Height/Depth128 mm

IFTTT support availableNo

Compatible with Amazon AlexaNo

Compatible with Apple HomeKitNo

Compatible with Google AssistantNo

Constant luminous flux controlNo

Power factor0.98

Luminaire with limited surface temperature D-mark according to EN 60598-2-24Yes

Luminaire luminous efficacy59lm/W

LampsLED not replaceable

Light emissionDirect

Light colorWhite

Luminous flux4023lm

Luminous flux adjustableNo

Lumen maintenance at average service life of 50,000 hours at 25 °C ambient temperature.80 %

Light distributorReflector

Light distributionAsymmetrical

Length620 mm

Max. number of luminaires Circuit breaker B1622

Max. number of luminaires Circuit breaker C1636

With operating deviceYes

With motion detectorNo

With light sourceYes

With light sensorNo

With air slotsNo

Nominal voltage230 to 240 V

Rated current235mA

Emergency power supply integratedNo

Surface protection housingPowder coated

Without dimming functionYes

Photobiological safety according to EN 62471RG1

IP protection)IP65

Protection classII

Voltage typeAC/DC

System performance54W

Temperature-40 to 40 °C

Cover materialPlastic opal

Housing materialAluminum
