With switchNo
HABIlia-ILG/1500 5300lm 840 ET vw
HAN16175024100
GTIN4020863329915
Covering the luminaire with thermal insulation material possibleNo
Connection typePlug-in terminal
Type of wiringDiploma
Rated lifetime L80/B10 at 25 °C50000 hours
Rated luminous flux according to IEC 62722-2-15300lm
Operating deviceLED control gear current controlled
Width56 mm
Dimming 0-10 VNo
Dimming 1-10 VNo
Dimming DALINo
Dimming DMXNo
Dimming DSINo
Dimming GPRSNo
Dimming LineSwitchNo
Dimming mains voltage modulationNo
Dimming trailing edgeNo
Dimming phase controlNo
Dimming potentiometer (integrated)No
Dimming RFNo
Dimming Sine Wave ReductionNo
Dimming Touch and DimNo
Dimming ZigbeeNo
Dimming manufacturer-specificNo
Dimming with push buttonNo
Dimming programmableNo
Electrical connection with plug-in systemNo
Color temperature4000K
Color rendering index CRI80-89
VersionWithout
Suitable for lamp power47W
Suitable for number of lamps1
Suitable for emergency lightingNo
Housing colorWhite
Glow wire test according to IEC 60695-2-11850 °C - 30 s
Height/Depth66 mm
Luminaire with limited surface temperature D-markNo
LampsLED not replaceable
Light colorWhite
Light distributorDiffuser lens/optics/panel
Length1420 mm
Max. system performance47W
With operating deviceYes
With motion detectorNo
With light sourceYes
Nominal voltage230V
Without dimming functionYes
Number of poles3
IP protection)IP20
Protection class (NEMA)Other
Protection classI
Voltage typeAC
MaterialSteel
