HABZatta-ZTTAXB-2 830 ET vw
HAN41231034130
GTIN4020863378890
Connection typeOther
Type of wiringWith through wiring
Rated luminous flux according to IEC 62722-2-16100lm
Rated ambient temperature according to IEC62722-2-110 to 35 °C
Operating deviceLED control gear current controlled
Width119 mm
Dimming 0-10 VNo
Dimming 1-10 VNo
Dimming DALINo
Dimming DMXNo
Dimming DSINo
Dimming GPRSNo
Dimming LineSwitchNo
Dimming mains voltage modulationNo
Dimming trailing edgeNo
Dimming phase controlNo
Dimming potentiometer (integrated)No
Dimming RFNo
Dimming Sine Wave ReductionNo
Dimming Touch and DimNo
Dimming ZigbeeNo
Dimming manufacturer-specificNo
Dimming with push buttonNo
Dimming programmableNo
Color temperature3000K
Color rendering index CRI80-89
VersionWithout
Suitable for lamp power43W
Suitable for number of lamps1
Suitable for emergency lightingNo
Housing colorWhite
Glow wire test according to IEC 60695-2-11Without
Height/Depth32 mm
Luminaire with limited surface temperature D-markNo
LampsLED not replaceable
Light colorWhite
Light distributorFocus lens
Light distributionSymmetrical
Length617 mm
Max. system performance43W
With operating deviceYes
With light sourceYes
With protective coverNo
Nominal voltage230V
Without dimming functionYes
Number of poles3
ReflectorWithout
Impact resistanceIK03
IP protection)IP20
Protection class (NEMA)Other
Protection classI
Voltage typeAC
Housing materialSteel
