Total harmonic distortion (THD)0.10
HABDeecos 47W-3000K Ra92 D123
HAN742182.003
GTIN4051859751182
Covering the luminaire with thermal insulation material possibleYes
Type of wiringDiploma
Beam angleMedium beam 21-40°
Outer diameter123 mm
Rated luminous flux according to IEC 62722-2-14950lm
Rated ambient temperature according to IEC62722-2-125°C
Operating deviceLED control gear current controlled
Suitable for computer workstations according to EN 12464-1Yes
Dimming 0-10 VNo
Dimming 1-10 VNo
Dimming DALINo
Dimming DMXNo
Dimming DSINo
Dimming GPRSNo
Dimming LineSwitchNo
Dimming mains voltage modulationNo
Dimming trailing edgeNo
Dimming phase controlNo
Dimming potentiometer (integrated)No
Dimming RFNo
Dimming Sine Wave ReductionNo
Dimming Touch and DimNo
Dimming ZigbeeNo
Dimming depends on the control gearNo
Dimming manufacturer-specificNo
Dimming with push buttonNo
Dimming programmableNo
Color consistency (McAdam ellipse)SDCM2
Color temperature3000K
Color rendering index CRI90-100
VersionWithout
Suitable for surface mountingNo
Suitable for ceiling mountingNo
Suitable for flush mountingNo
Suitable for clamp mountingNo
Suitable for lamp power43W
Suitable for number of lamps1
Suitable for pendulum suspensionNo
Suitable for podium/floor mountingNo
Suitable for rope systemNo
Suitable for busbar mountingYes
Suitable for truss mountingNo
Housing colorBlack
Glow wire test according to IEC 60695-2-11650 °C - 30 s
Height/Depth200 mm
LED nominal current at constant current179 to 195 mA
Power factor0.90
Luminaire with limited surface temperature D-markNo
Luminaire luminous efficacy116lm/W
LampsLED not replaceable
Light emissionDirect
Light colorWhite
Luminous flux4950lm
Light distributorReflector
Light distributionSymmetrical
Max. system performance43W
With operating deviceYes
With motion detectorNo
With light sourceYes
With light sensorNo
Nominal voltage220 to 240 V
SurfacePowder coated
Brushed surfaceNo
Without dimming functionYes
Photobiological safety according to EN 62471RG1
Number of poles2
ReflectorOther
Impact resistanceIK06
IP protection)IP20
Protection class (NEMA)Other
Protection classI
Voltage typeAC
AdjustabilityRotatable and pivotable
Housing materialAluminum
