HABRond41S 1350lm830/840 ML PMMA
HAN51WD107AG1A
GTIN4058352520949
Covering the luminaire with thermal insulation material possibleNo
Connection typeOther
Execution of the gridWithout
Beam angleFree-radiating/diffuse
Outer diameter280.00 mm
Rated lifetime L80/B10 at 25 °C50000.00h
Rated luminous flux according to IEC 62722-2-11350.00lm
Rated ambient temperature according to IEC62722-2-1-30 to 40 °C
Operating deviceElectronic ballast
Suitable for computer workstations according to EN 12464-1No
Dimming 0-10 VNo
Dimming 1-10 VNo
Dimming DALINo
Dimming DMXNo
Dimming DSINo
Dimming GPRSNo
Dimming LineSwitchNo
Dimming mains voltage modulationNo
Dimming trailing edgeNo
Dimming phase controlNo
Dimming potentiometer (integrated)No
Dimming RFNo
Dimming Sine Wave ReductionNo
Dimming Touch and DimNo
Dimming ZigbeeNo
Dimming depends on the control gearNo
Dimming manufacturer-specificNo
Dimming with push buttonNo
Dimming programmableNo
Color temperature3000 to 4000 K
Color rendering index CRI80-89
Suitable for surface mountingYes
Suitable for ceiling mountingYes
Suitable for flush mountingNo
Suitable for light strip configurationNo
Suitable for emergency lightingNo
Suitable for pendulum suspensionNo
Suitable for wall mountingYes
Housing colorWhite
Height/Depth100 mm
Luminaire with limited surface temperature D-markNo
Luminaire luminous efficacy104lm/W
LampsLED not replaceable
Light emissionDirect
Light colorWhite
Light distributionSymmetrical
Max. system performance13 W
With operating deviceYes
With motion detectorNo
With light sourceYes
With light sensorNo
With air slotsNo
Nominal voltage230V
Without dimming functionYes
Impact resistanceIK02
IP protection)IP44
Protection classI
Voltage typeAC
Cover materialPlastic opal
