Spittler 8713661503430 LED surface-mounted light 4000K 46W converter microprism

In stock
SKU: 129250
€543.13
Into a basketIn the basketGo

Overview

SL 713 surface-mounted luminaire with high-performance LED, luminaire output 46W, standard-compliant glare-free workplace luminaire for flexible and individual arrangement, particularly innovative and efficient thanks to extra-flat design (13mm), perfect optics thanks to high-quality profile connections, luminaire housing consisting of Thin-Skate extruded aluminum profile, use for innovative and comfortable office lighting, luminaire housing made of extruded aluminum profile, scratch-resistant surface finish thanks to high-quality powder coating after microprism cover for efficient light scattering, glare minimization and high uniformity, integrated highly transmitting light guide, direct beam with corona for ceiling illumination, homogeneous luminance distribution over the entire light emission surface (LED sidelight technology), floating appearance of the luminaire in the room thanks to ceiling illumination (corona), glare-free microprism cover ensures an attractive room atmosphere, BAP-suitable according to DIN EN 12464-1,

Property Value
Suitable for wall mounting: Yes
Suitable for pendant suspension: No
Suitable for ceiling mounting: Yes
Suitable for recessed mounting: No
Suitable for surface mounting: Yes
Light source: LED not replaceable
With light source: Yes
Socket: other
Suitable for number of bulbs: 1
Lamp wattage: 41 W
Lamp wattage at Multiwatt: not applicable
Operating device: LED operating device, current-controlled
With operating device: Yes
Type of dimming: not dimmable
Circuit: other
Suitable for emergency lighting: No
Emergency lighting component integrated: No
Nominal voltage: 220 - 240 V
Nominal current: 192 - 209 mA
Color temperature: 4000 - 4000 K
Housing material: Aluminum
Surface finish: matt
Housing color: white
Suitable for light strip configuration: No
Cover material: Structured plastic
Suitable for computer workstations: Yes
Design of the grid: without
Light distribution: symmetrical
Beam angle: extremely wide beam >80°
Light emission: direct/indirect
Length: 615 mm
Width: 615 mm
Height/Depth: 52 mm
With motion detector: No
With light sensor: No
Protection class: I
Protection type (IP): IP20
Impact resistance: IK05
Fire protection 'D': No
Installation in insulated ceilings, fire protection 'F with roof': No
Ambient temperature: 10 - 35 °C
Glow wire test according to IEC 60695-2-10: 650 °C - 30 s
System power: 46 W
With air slots: No
Voltage type: AC
Effective luminous flux: 4740 lm
Light color: white
Color rendering index CRI: 80-89

Characteristics

ManufacturerSpittler
HAN8713661503430
GTIN4052075131574
Surface finishFrosted
Execution of the gridWithout
Operating deviceLED control gear current controlled
Width615 mm
Color temperature4000 - 4000K
Color rendering index CRI80-89
VersionOther
Suitable for surface mountingYes
Suitable for ceiling mountingYes
Suitable for flush mountingNo
Suitable for number of lamps1
Suitable for light strip configurationNo
Suitable for emergency lightingNo
Suitable for pendulum suspensionNo
Suitable for wall mountingYes
Housing colorWhite
Height/Depth52 mm
Lamp power41 W
LampsLED not replaceable
Light emissionDirect/indirect
Light colorWhite
Light distributionSymmetrical
Length615 mm
With operating deviceYes
With motion detectorNo
With light sourceYes
With light sensorNo
With air slotsNo
Nominal voltage220 - 240V
Rated current192 - 209mA
Impact resistanceIK05
Protection classI
Voltage typeAC
System performance46W
Ambient temperature10 - 35 °C
Cover materialPlastic structured
Housing materialAluminum
