Spittler MIMIK 30 CP/T3 30W 3000K ANTR LED recessed ceiling spotlight

Spittler MIMIK 30 CP/T3 30W 3000K ANTR LED recessed ceiling spotlight

In stock

SKU: 845085

Price on request

€251.15

€0

Overview

Wall light for indoor and outdoor use, comprising: Die-cast aluminium housing with polyester powder coating. Diffuser made of tempered, transparent flat glass, screen-printed inside for the MIMIK version. Silicone gasket. LED versions are supplied with a 230/240 V 50/60 Hz safety transformer. The MIMIK versions have optics with lenses made of high-performance polymer with high light rendering and different beam angles to meet different lighting requirements. Polyester powder coating, consisting of 13 different layers, protects against UV radiation. The models with CP optics have an asymmetrical light distribution and are particularly suitable for lighting cycle paths and footpaths.

Feature	Value
System power:	30 W
Luminous flux:	2558 lm
Number of LM:	1
Length:	63 mm
Width:	300 mm
Height/depth:	125 mm
Protection class (IP):	IP65
Protection class:	I
Luminaire with limited surface temperature D-mark according to EN 60598-2-24:	no
Nominal voltage:	220 to 240 V
Housing color:	anthracite
Housing material:	aluminum
Color temperature:	3000 K
Impact resistance:	IK06
Color rendering index CRI:	70-79
Suitable for ceiling mounting:	no
Voltage type:	AC
With motion detector:	no
Beam angle:	extremely wide beam >80°
With light source:	yes
Light source:	LED not replaceable
Temperature:	-20 to 25 °C
Socket:	other
With operating device:	yes
Cover material:	opal glass
Without dimming function:	yes
Light emission:	direct
Light distribution:	asymmetrical
With light sensor:	no
Operating device:	LED operating device current controlled
Suitable for recessed mounting:	no
Light colour:	white
Suitable for computer workstations in accordance with EN 12464-1:	no
Suitable for light strip configuration:	no
Suitable for pendulum suspension:	no
Suitable for surface mounting:	no
Suitable for emergency lighting:	no
Design of the Grid:	without
Covering of the lamp with thermal insulation material possible:	no
Dimming DMX:	no
Dimming DSI:	no
With air slots:	no
Dimming LineSwitch:	no
Dimming potentiometer (integrated in the device):	no
Dimming 0-10 V:	no
Dimming 1-10 V:	no
Dimming manufacturer-specific:	no
Dimming DALI:	no
Dimming mains voltage modulation:	no
Dimming trailing edge:	no
Dimming leading edge:	no
Dimming programmable:	no
Dimming RF:	no
Dimming Sine Wave Reduction:	no
Dimming Touch and Dim:	no
Dimming Zigbee:	no
Dimming with push button:	no
Glow wire test according to IEC 60695-2-11:	without
Suitable for lamp power:	30 W
Surface protection housing:	painted
Replaceable operating device:	yes
DALI-2 dimming:	no
Color consistency (McAdam ellipse):	SDCM3
Luminous flux maintenance with an average service life of 35,000 hours at an ambient temperature of 25 °C:	99 %
Luminous flux maintenance with an average service life of 50,000 hours at an ambient temperature of 25 °C:	98.3 %
Luminous flux maintenance with an average service life of 50,000 hours at an ambient temperature of 25 °C: Service life 75,000 h at 25 °C ambient temp.:	97.1 %
Max. number of luminaires with circuit breaker B16:	69
Max. Number of lights circuit breaker C16:	69
Integrated emergency power supply:	no
Constant luminous flux control:	no
Total harmonic distortion (THD):	13
Photobiological safety in accordance with EN 62471:	RG0
Adjustable color temperature:	no
Adjustable luminous flux:	no
Adjustable beam angle:	no
Operation via Bluetooth:	no
Compatible with Apple HomeKit:	no
Compatible with Google Assistant:	no
Compatible with Amazon Alexa:	no
IFTTT support available:	no

Characteristics

Number of LM1

Total harmonic distortion (THD)13

HABMIMIK 30 CP/T3 30W 3000K ANTR

Manufacturer

HAN303809

GTIN8018367620986

Covering the luminaire with thermal insulation material possibleNo

Execution of the gridWithout

Beam angle adjustableNo

Replaceable operating deviceYes

Operation via BluetoothNo

Operating deviceLED control gear current controlled

Suitable for computer workstations according to EN 12464-1No

Width300 mm

Dimming 0-10 VNo

Dimming 1-10 VNo

Dimming DALINo

Dimming DALI-2No

Dimming DMXNo

Dimming DSINo

Dimming LineSwitchNo

Dimming mains voltage modulationNo

Dimming trailing edgeNo

Dimming phase controlNo

Dimming potentiometer (integrated)No

Dimming RFNo

Dimming Sine Wave ReductionNo

Dimming Touch and DimNo

Dimming ZigbeeNo

Dimming manufacturer-specificNo

Dimming with push buttonNo

Dimming programmableNo

Color consistency (McAdam ellipse)SDCM3

Color temperature3000K

Color temperature adjustableNo

Color rendering index CRI70-79

VersionOther

Suitable for surface mountingNo

Suitable for ceiling mountingNo

Suitable for flush mountingNo

Suitable for lamp power30W

Suitable for light strip configurationNo

Suitable for emergency lightingNo

Suitable for pendulum suspensionNo

Housing colorAnthracite

Glow wire test according to IEC 60695-2-11Without

Height/Depth125 mm

IFTTT support availableNo

Compatible with Amazon AlexaNo

Compatible with Apple HomeKitNo

Compatible with Google AssistantNo

Constant luminous flux controlNo

Luminaire with limited surface temperature D-mark according to EN 60598-2-24No

LampsLED not replaceable

Light emissionDirect

Light colorWhite

Luminous flux2558lm

Luminous flux adjustableNo

Lumen maintenance at average service life of 50,000 hours at 25 °C ambient temperature.98.3 %

Light distributionAsymmetrical

Length63 mm

Max. number of luminaires Circuit breaker B1669

Max. number of luminaires Circuit breaker C1669

With operating deviceYes

With motion detectorNo

With light sourceYes

With light sensorNo

With air slotsNo

Nominal voltage220 to 240 V

Emergency power supply integratedNo

Surface protection housingPainted

Without dimming functionYes

Photobiological safety according to EN 62471RG0

Impact resistanceIK06

IP protection)IP65

Protection classI

Voltage typeAC

System performance30W

Temperature-20 to 25 °C

Cover materialGlass opal

Housing materialAluminum
