Spittler 303747 LED wall light 3000K 1x13.5W Power LED asymmetric

Spittler 303747 LED wall light 3000K 1x13.5W Power LED asymmetric

In stock

SKU: 208752

Price on request

€211.60

€0

Overview

Wall light for indoor and outdoor use, comprising: Body made of painted die-cast aluminum, Diffuser with microprism - made of tempered flat glass, screen-printed inside for the MIMIK FLAT version, Silicone gasket, LED versions are supplied with a 230/240 V 50/60 Hz safety transformer, The MIMIK versions have optics with lenses made of high-performance polymer with high light rendering and different beam angles to meet the different lighting requirements, Polyester powder coating, consisting of 13 different layers, protects against UV radiation, The M versions, single spotlights, use only one light source for light emission upwards or downwards

Feature	Value
Suitable for wall mounting:	Yes
Suitable for pendant suspension:	No
Suitable for ceiling mounting:	No
Suitable for recessed mounting:	No
Suitable for surface mounting:	No
Light source:	LED not replaceable
With light source:	Yes
Socket:	other
Suitable for number of light sources:	1
Lamp power:	13.5 W
Lamp power at Multiwatt:	not applicable
Operating device:	LED operating device, current-controlled
With operating device:	Yes
Type of dimming:	not dimmable
Circuit:	other
Suitable for emergency lighting:	No
Emergency lighting component integrated:	No
Nominal voltage:	220 - 240 V
Color temperature:	3000 - 3000 K
Housing material:	aluminum
Surface finish:	matt
Housing color:	anthracite
Suitable for light strip configuration:	No
Cover material:	opal glass
Suitable for computer workstations:	No
Design of the grid:	without
Reflector:	without
Light distribution:	asymmetrical
Beam angle:	wide beam 40-80°
Light emission:	direct
Length:	200 mm
Width:	200 mm
Height/depth:	42 mm
With motion detector:	No
With light sensor:	No
Protection class:	I
Protection type (IP) :	IP65
Impact resistance:	IK06
Fire protection 'D':	No
Installation in insulated ceilings, fire protection 'F with roof':	No
Ambient temperature:	-20 - 45 °C
Glow wire test according to IEC 60695-2-10:	without
With air slots:	No
Voltage type:	AC
Effective luminous flux:	864 lm
Light color:	white
Color rendering index CRI:	80-89

Characteristics

HAB303747

Manufacturer

HAN303747

GTIN8018367619058

Surface finishFrosted

Execution of the gridWithout

Beam angleWide beam 40-80°

Operating deviceLED control gear current controlled

Width200 mm

Color temperature3000 - 3000K

Color rendering index CRI80-89

VersionOther

Suitable for surface mountingNo

Suitable for ceiling mountingNo

Suitable for flush mountingNo

Suitable for number of lamps1

Suitable for light strip configurationNo

Suitable for emergency lightingNo

Suitable for pendulum suspensionNo

Suitable for wall mountingYes

Housing colorAnthracite

Height/Depth42 mm

Lamp power13.5W

LampsLED not replaceable

Light emissionDirect

Light colorWhite

Light distributionAsymmetrical

Length200 mm

With operating deviceYes

With motion detectorNo

With light sourceYes

With light sensorNo

With air slotsNo

Nominal voltage220 - 240V

ReflectorWithout

Impact resistanceIK06

Protection classI

Voltage typeAC

Ambient temperature-20 - 45 °C

Cover materialGlass opal

Housing materialAluminum
