Bridging switchYes
With signal unitYes
Response brightness2 to 2000 lx
Forced shutdownYes
Max. inrush current800 A
Forced switching onYes
Max. presence range15 m²
HABCOM2 UP
HAN057947
GTIN4007841057947
Dimming function with dimming insertNo
Alarm functionNo
Connection typeOther
Response sensitivity adjustableYes
Response brightness adjustableYes
Antibacterial treatmentNo
Width103 mm
Installation length29 mm
Detection angle horizontal360°
Remote controllableYes
Suitable for C-loadYes
Suitable for ceiling mountingYes
Suitable for wireless transmissionYes
HVAC controlYes
Halogen freeYes
Height103 mm
Constant light controlNo
Max. duty cycle60 min
Max. range frontal7.5m
Max. range to one side7.5m
Min. duty cycle20s
Min. depth of the device box66 mm
With DALI interfaceNo
With remoteNo
Mounting typeFlush-mounted
Surface protectionOther
RAL number (similar)9003
IP protection)IP20
Sensor typeHigh frequency
Voltage typeAC
Teach function for response brightnessYes
Temperature-20 to 50 °C
Animal corridorNo
TransparentNo
NetworkableYes
MaterialPlastic
Material qualityThermoplastic
