Energy efficiency class of the permanently installed light sourceOther
HAB7651 HE PW160-840ET L225 01p6
HAN9002027857
GTIN4018242490332
Connection typePlug-in terminal
Type of wiringSuitable for through wiring
Rated luminous flux according to IEC 62722-2-116800lm
Operating deviceElectronic transformer
Width71 mm
Dimming 0-10 VNo
Dimming 1-10 VNo
Dimming DALINo
Dimming DMXNo
Dimming DSINo
Dimming GPRSNo
Dimming LineSwitchNo
Dimming mains voltage modulationNo
Dimming trailing edgeNo
Dimming phase controlNo
Dimming potentiometer (integrated)No
Dimming RFNo
Dimming Sine Wave ReductionNo
Dimming Touch and DimNo
Dimming ZigbeeNo
Dimming manufacturer-specificNo
Dimming with push buttonNo
Dimming programmableNo
Color temperature4000K
Color rendering index CRI80-89
VersionOther
Suitable for number of lamps1
Suitable for emergency lightingNo
Housing colorWhite
Glow wire test according to IEC 60695-2-11650 °C - 30 s
Height/Depth77 mm
Power factor0.95
LampsLED not replaceable
Light emissionDirect
Light colorWhite
Light distributorOther
Light distributionSymmetrical
Length2211 mm
Max. system performance101 W
With operating deviceYes
With light sourceYes
Nominal voltage220 to 240 V
Without dimming functionYes
Number of poles3
ReflectorWithout
IP protection)IP20
Protection classI
Voltage typeAC
Housing materialSteel
