LEDVANCE Osram 4052899438965 Bx-xS-PL 830 G15 D 60W 12V FS1 LED module

In stock
SKU: 705530
€403.21
Into a basketIn the basketGo

Overview

Product family advantages: Uniform illumination thanks to optimized elliptical lenses. Click and Play: Simple, quick and tool-free snapping of the LED modules. Excellent module efficiency. Very long service life. 5-year guarantee. Product family properties: Connected with flexible cables. Protection class (modules): IP66. Special robust casting. With CE marking. Areas of application: Permanent outdoor use in closed light boxes. Illuminated advertising and illuminated signs. Lighting of single and double-sided light boxes. Facade lighting, cove lighting. Technical equipment: Various OPTOTRONIC© 12 V control gear available. BackLED mounting profile BA-MP.

PropertyValue
Color temperature:3000 K
Energy efficiency class:G
Protection class (IP) :IP66
Number of LEDs:3
Beam angle:12 °
Length:104.0 mm
Width:17.5 mm
Height:14.5 mm
Shape:other
Color:white
Suitable for traffic information board signalling:no
Suitable for traffic lights:no
Suitable for variable message signs:no
Connection type:other
Suitable for rail traffic:no
Luminous flux:3652 lm
Suitable for constant current:no
Suitable for general lighting:yes
Suitable for constant voltage:yes
Average Nominal service life:50000 h
External operating device required:yes
Voltage type:DC
Operating current:5000 mA
Operating voltage:12 V
Lamp voltage:12 V
Lamp power:60.00 W
Light color according to EN 12464-1:warm white <,3300 K

Characteristics

Suitable for constant currentNo
Suitable for constant voltageYes
Operating voltage12 V
HABBx-xS-PL 830 G15 D 60W 12V FS1
ManufacturerLEDVANCE Osram
HAN4052899438965
GTIN4052899438965
Connection typeOther
Beam angle12°
Width17.5 mm
Energy efficiency classG
ColorWhite
Color temperature3000K
ShapeOther
Height14.5 mm
Lamp power60.00W
Lamp voltage12V
Light colour according to EN 12464-1Warm white <,3300 K
Luminous flux3652lm
Length104.0 mm
Average nominal life50000 hours
Voltage typeDC
LEDVANCE Osram 4052899438965 Bx-xS-PL 830 G15 D 60W 12V FS1 LED module
LEDVANCE Osram 4052899438965 Bx-xS-PL 830 G15 D 60W 12V FS1 LED module
