Product family advantages: High luminous flux. Great design freedom thanks to the flexibility and cuttability of the module. High-performance silicone for an extremely long service life and flexibility. Easy contacting thanks to the pre-assembled plug. Special design and high-quality materials. Toolless connection only if using the optional CONNECT system. Easy installation on many smooth surfaces thanks to the self-adhesive tape on the back. Outdoor use possible: UV and salt resistance (UV according to DIN EN 4892-2 - method A, salt resistance according to IEC 60068-2-52 test method 1). Product family properties: Flexible and divisible LED strip. Luminous flux: up to 1,200 lm/m. Protection class: IP67. Dimmable with PWM technology. Fine White (3.5 SDCM). Areas of application: Facade accentuation. Ceiling integration. Wall integration. Cove lighting. Machine lighting. Path lighting. Suitable for outdoor use. Technical equipment: Easier connection with the optional, matching CONNECT system. Quick installation with optional SLIM TRACK system.
| Property | Value |
| Lamp power per meter: | 10.6 W |
| With connection set: | yes |
| Length of the individual sections: | 14.3 mm |
| Number of lamps per meter: | 70 |
| Smallest bending radius: | 50 mm |
| Width: | 11.1 mm |
| Length: | 9000 mm |
| Beam angle: | 120 ° |
| Design: | Band |
| With End piece: | yes |
| Color temperature: | 2400 K |
| Light source: | LED not replaceable |
| Protection class (IP) : | IP67 |
| Self-adhesive: | yes |
| Voltage type: | DC |
| Number of lamps per base: | 21 |
| Lamp power per base: | 3.2 W |
| Luminous flux per meter: | 1100 lm |
| Lamp voltage: | 24 V |
| Energy efficiency class of the built-in Light source: | G |
| Max. system power: | 63 W |
| Light color: | white |
| Color rendering index CRI: | 80-89 |
| Height/depth: | 4.80 mm |
| With protective cover: | yes |
| Number of poles: | 2 |
| Connection type: | other |
