LEDVANCE Osram 4058075752603 SMART WIFIPLANPLUSRGBFR300X300RGBTW LED recessed luminaire

LEDVANCE Osram 4058075752603 SMART WIFIPLANPLUSRGBFR300X300RGBTW LED recessed luminaire

In stock

SKU: 1063318

Price on request

€75.26

€0

Overview

Panel lights with WiFi technology. Product features: Can be controlled via LEDVANCE SMART+ WiFi app (with at least AndroidT 4.4 or iOS 10.0). Can be controlled via Google Assistant or Amazon Alexa. RGB color control, approx. 16 million color options can be set. Dimmable. Color temperature: 3,000 K (warm white). Network protocol: WiFi. Product advantages: Simple and quick installation. Areas of application: Indoor applications. Kitchen, living room, children's room or study. Technical equipment: Support bracket included. Includes mounting screws and dowels. Control via app or voice control requires a compatible smart home system. A smartphone or tablet is required for control via LEDVANCE SMART + WiFi app.

Property	Value
Rated luminous flux according to IEC 62722-2-1:	1300 lm
Color temperature:	2700 - 6500 K
Protection class (IP):	IP20
Protection class:	II
Rated ambient temperature according to IEC62722-2-1:	-20 - 40 °C
Length:	295.00 mm
Width:	295.00 mm
Height / Depth:	51.00 mm
Voltage type:	AC
Nominal voltage:	220 - 240 V
Max. System power:	18.00 W
Luminaire luminous efficacy:	72 lm/W
With control gear:	yes
Control gear:	EVG
Connection type:	Plug terminal
Number of poles:	2
Type of wiring:	Terminal
With light source:	yes
Light source:	LED not replaceable
Housing color:	white
Suitable for Surface mounting:	yes
Suitable for ceiling mounting:	yes
Photobiological safety according to EN 62471:	RG0
Stroboscopic effect value SVM:	0.4
Weight:	1.38
Weight unit:	KG
Grid design:	matt
Nominal current:	80,000 mA
Rated service life L70/B50 at 25 °C:	40,000 h
Compatible with Google Assistant:	yes
Compatible with Amazon Alexa:	yes
Max. number of lights circuit breaker C16:	47
Max. number of lights circuit breaker B16:	37
Adjustable color temperature:	continuously
Adjustable luminous flux:	continuously
Socket:	other
Short description:	SMART+ Planon Plus RGBW 300x300mm RGB + TW

Characteristics

Stroboscopic effect value SVM0.4

HABSMART WIFIPLANPLUSRGBFR300X300RGBTW

Manufacturer

HAN4058075752603

GTIN4058075752603

Connection typePlug-in terminal

Type of wiringDiploma

Execution of the gridFrosted

Rated lifetime L70/B50 at 25 °C40000 hours

Rated luminous flux according to IEC 62722-2-11300lm

Rated ambient temperature according to IEC62722-2-1-20 - 40 °C

Operating deviceElectronic ballast

Width295.00 mm

Color temperature

Color temperature adjustableContinuously variable

VersionOther

Suitable for surface mountingYes

Suitable for ceiling mountingYes

Housing colorWhite

Weight1,38

Weight unit kg

Height/Depth51.00 mm

Compatible with Amazon AlexaYes

Compatible with Google AssistantYes

Short descriptionSMART+ Planon Plus RGBW 300x300 mm RGB + TW

Luminaire luminous efficacy72lm/W

LampsLED not replaceable

Luminous flux adjustableContinuously variable

Length295.00 mm

Max. number of luminaires Circuit breaker B1637

Max. number of luminaires Circuit breaker C1647

Max. system performance18.00 W

With operating deviceYes

With light sourceYes

Nominal voltage

Rated current80,000mA

Photobiological safety according to EN 62471RG0

Number of poles2

IP protection)IP20

Protection classII

Voltage type
