HABPL COMP 600 V 33W 840 U19
HAN4099854017223
GTIN4099854017223
Connection typePlug-in terminal
Type of wiringSuitable for through wiring
Execution of the gridHigh gloss
Replaceable operating deviceYes
Rated lifetime L70/B50 at 25 °C70000 hours
Rated luminous flux according to IEC 62722-2-13630lm
Rated ambient temperature according to IEC62722-2-1-10 - 45 °C
Suitable for computer workstations according to EN 12464-1Yes
Width595.00 mm
Installation width575 mm
Installation height/depth50.0 mm
Installation length575 mm
Color consistency (McAdam ellipse)SDCM5
Suitable for surface mountingYes
Suitable for ceiling mountingYes
Suitable for flush mountingYes
Suitable for emergency lightingYes
Suitable for pendulum suspensionYes
Housing colorWhite
Weight1,79
Weight unit kg
Height/Depth50.0 mm
Short descriptionPANEL COMPACT 600 UGR<,19 33W 840 U19
Luminaire luminous efficacy110lm/W
Light emissionDirect
Light distributorDiffuser lens/optics/panel
Length595.00 mm
Max. number of luminaires Circuit breaker B1661
Max. number of luminaires Circuit breaker C1678
Max. system performance33.00W
With operating deviceYes
With light sourceYes
Rated current150,000mA
Without dimming functionYes
Photobiological safety according to EN 62471RG0
Number of poles2
Impact resistanceIK02
IP protection)IP40
Protection classII
