AC/DC voltage tester up to 690 V with LED and LCD display, continuity test with optical and acoustic display, integrated single-pole test, automatic polarity detection, bright LED display, integrated flashlight, impact-resistant, modernly designed housing, quick one-handed testing on safety sockets, test probe protection. Display: 1 LCD 3 digits, 12 LEDs (+12 V, -12 V, 24 V, 50 V, 120 V, 230 V, 400 V, 690 V), single pole test, continuity test, ELV, rotating field L/R, voltage range 12 - 690 V AC/DC, automatic polarity display, frequency range AC, 40 - 400 Hz, current consumption < 3.5 mA, single pole test > 90 690 V AC, optical and acoustic continuity test, measuring category: CAT IV 600 V, CAT III 1000 V, protection level: IP 64, tested according to EN 61010, EN 61243-3:2010, TÃoV / GS certified, overvoltage category CAT III / IV, cable length: 1.2 m, weight: 180 g, Incl. 2 batteries 1.5V AAA, LR03
Property | Value |
Length: | 240 mm |
Voltage display: | LED/LCD |
Voltage measuring range: | 12 to 690 V |
Internal base load: | yes |
Continuity display: | optical/acoustic |
Single-pole phase display: | yes |
Contactless voltage detection: | no |
Instantaneous value memory (data hold): | no |
LC display backlight: | yes |
Measuring tip protection: | yes |
Measuring point illumination: | yes |
Test type: | 2-pole |
Load can be switched on: | no |
Rotation field direction indicator: | yes |
Power supply: | Battery |
Measuring circuit category: | CAT IV |
Continuity test: | yes |
Can be used in precipitation: | yes |
