HellermannTyton 121-98160 KR8/S1-W-BK-I1 cable tie reel

In stock
SKU: 630236
€61.92
Into a basketIn the basketGo

Overview

Robust cable tie without teeth. Damage to cables and lines is avoided. Locking head with glass fiber reinforced pin. Very secure and vibration-resistant binding. Endless band with separate heads for extra large bundle diameters. Offers high flexibility and can be cut to any bundle. A special KR tool is required for binding. This cable tie is characterized by its smooth inside and unique locking mechanism. The beveled head of the KR series adapts wonderfully to the bundled goods. Their special design ensures that cables and lines are securely bundled even in difficult environments. The cable ties of the KR series are particularly suitable for attaching bellows to steering gears, water hoses and vacuum lines. The PA12 material in combination with the vibration-resistant closure is very popular in the automotive industry. The endless band of the KR series ensures high flexibility with different or changing bundle diameters. It can be cut to any desired length and closed with separate heads.

PropertyValue
Band width:8.0 mm
Band length:50000 mm
Band closure:Fiberglass pin
Color:black
Material:Plastic
Band thickness:2.05 mm
Removable closure:no
Design:without teeth
Fastening type:other
UV-stable according to ASTM D6779:yes
Min. holding force:785 N
Material quality:Polyamide (PA)
Surface:untreated
Transparent:no
Reflective (luminous color):no
Operating temperature:-40 to 85 °C
Flammability class of the insulating material according to UL 94:V2

Characteristics

HABKR8/S1-W-BK-I1
ManufacturerHellermannTyton
HAN121-98160
GTIN4031026114309
VersionWithout gearing
Strip thickness2.05 mm
Band length50000 mm
Band closureFiberglass pen
Mounting typeOther
Operating temperatur-40 to 85 °C
Width of the band8.0 mm
Flammability class of the insulating material according to UL 94V2
ColorBlack
Removable closureNo
Min. holding force785 N
SurfaceUntreated
Reflective (luminous color)No
TransparentNo
UV-stable according to ASTM D6779Yes
MaterialPlastic
Material qualityPolyamide (PA)
