![CDATA[DALI LED driver (CC) with 2 output channels, control of Tunable White capable luminaires via DALI address (DT8). Operating modes: Balance&Dim, Dim2Warm, SwitchDim2 (control option via 2 button inputs without DALI) Electrical data: Supply Uin: 12VDC-48VDC Max. connection current Iinmax: 350mA/500mA Max. output current per channel: 350mA/500mA Output voltage range Uled: 3V-45V (with 48V supply) Control input: -DALI -SwitchDim2 Current requirement DALI: 2mA Number of DALI addresses: Operating mode DT8, Dim2Warm: 1 Operating mode Balance&Dim: 2 Standby losses (12V): ~ 180mW common positive pole Technical data: State after power on: adjustable via DALI: 0% to 100% or last value Storage and transport temperature: -20 to +75 degrees Celsius Operating temperature Ta: -20 to +60 degrees Celsius Expected service life: >,100000h at Tc<,75 degrees Celsius Protection class: IP20 max. cable cross-section: up to 1.5mm² -Supply (V+, V-): up to 2.5mm² Dimensions: 120mmx30mmx22mm Installation/housing shape: ceiling recessed]]>
